FOREWORD

• This manual includes procedures for diagnosis, maintenance and adjustments, minor service operations, removal disassembly and installation for components of GMC Series 1500-3500 Light Duty Trucks. Procedures for “S-15” and Caballero are contained in separate service manuals.
• The Section index on the contents page enables the user to quickly locate any desired section. At the beginning of each section containing more than one major subject is a Table of Contents, which gives the page number on which each major subject begins. An index is placed at the beginning of each major subject within the section. Summaries of Special Tools, when required, and specifications are found at the end of major sections.
• When reference is made in this manual to a brand name, number, or specific tool an equivalent product may be used in place of the recommended item. This manual should be kept in a handy place for ready reference, if properly used, it wil enable the technician to better serve the owners of GMC built vehicles. All information, illustrations and specifications contained in this literature are basic on the latest product information available at the time of publication approval. The right is reserved to make changes at any time without notice. GMC

CAUTION

• To reduce the chance of personal injury and/or property damage, the following instructions must be carefully observed: ‘ Proper service and repair are important to the safety of the service technician and the safe, reliable operation of all motor vehicles.
• If part replacement is necessary, the part must be replaced with one of the same part number or with an equivalent part. Do not use a replacement part of lesser quality. The service procedures recommended and described in this service manual are effective methods of performing service and repair.
• Some of these procedures require the use of tools specially designed for the purpose. Accordingly, anyone who intends to use a replacement part, service procedure or tool, which is not recommended by the vehicle manufacturer, must first determine that neither his safety nor the safe operation of the vehicle will be jeopardized by the replacement part, service procedure or tool selected.
• It is important to note that this manual contains various “Cautions” and “Notices” that must be carefully observed in order to reduce the risk of personal injury during service or repair, or the possibility that improper service or repair may damage the vehicle or render it unsafe.
• It is also important to understand that these ‘Cautions’ and ‘Notices’ are not exhaustive, because it is impossible to warn of all the possible hazardous consequences that might result from failure to follow these instructions.

TABLE OF CONTENTS:

GENERAL INFORMATION
General Information 0A
Maintenance and Lubrication OB
HEATING AND AIR CONDITIONING
Heating and Ventilation 1A
Air Conditioning 1B
A-6 Compressor – Unit Repair 1D
R-4 Compressor – Unit Repair 1D1
FRAME AND BUMPERS
Frame and Body Mounts 2A
Bumpers 2B
Sheet Metal 2C
STEERING. SUSPENSION. WHEELS
AND TIRES
Diagnosis 3
Front Alignment 3A
Steering Column 3B5
Steering Linkage 3B6
Power Steering 3B7
Manual Steering 3B8
Front Suspension 3C
Rear Suspension 3D
Wheel and Tires 3E
PROPELLER SHAFT AND AXLES
Propeller Shaft 4A
Rear Axles 4B
Front Axle 4C
BRAKES 5
ENGINE
Engine Diagnosis 6
In-Line 6 (4.1L/4.8L) 6A1
Small Block (5.0L75.7L) 6A2
Mark IV (7.4L) 6A5
Diesel (6.2L) 6A7
Engine Cooling 6B
Engine Fuel 6C
E4ME Carburetor 6C1
E2SE Carburetor 6C3
Diesel Fuel Injection 6C6
1ME Carburetor 6C7
2SE Carburetor 6C9
M4ME Carburetor 6C10
Engine Electrical 6D
Driveability & Emission – Carburetor 6E8
Driveability & Emission – Diesel 6E9
Engine Exhaust 6F
Vacuum Pump 6H
TRANSMISSION
Automatic — Service 7A
350C-Unit Repair
400-Unit Repair
700R4-Unit Repair
Manual-Service 7B
3 Speed 76mm-Unit Repair
4 Speed 89mm-Unit Repair
4 Speed 117mm-Unit Repair
Clutch 7C
Transfer Case 7D
205 – Unit Repair
208 – Unit Repair
ELECTRICAL
Chassis Electrical 8B
Instrument Panel and Gages 8C
ACCESSORIES 9
BODY SERVICE 10
ELECTRICAL WIRING DIAGRAMS
