DESCRIPTION:

2024+ RockShox Vivid – Complete Factory Service Manual

This is the official factory service manual published by SRAM, LLC for the 2024+ RockShox Vivid rear shock absorber line. This comprehensive technical guide provides professional bicycle mechanics and advanced home mechanics with complete service, rebuild, and tuning procedures for all Vivid C1 generation models used on mountain bikes, downhill bikes, and enduro racing bicycles.

File Details:

• Manual Name: 2024+ Vivid Service Manual
• Publisher: SRAM, LLC
• Document Number: GEN.0000000007397 Rev A
• Year: 2023/2024
• Generation: C1 (Third generation, first iteration)
• PDF Quality: Excellent – Factory original with clear photos and diagrams
• Total Pages: 113

MODELS COVERED (All 2024+ C1 Generation):

1. Vivid Ultimate RC2T (RS-VIVD-ULT-C1)
   • Top-tier model with RC2T compression damping
   • Dual compression adjustments (high and low speed)
   • Threshold (pedal) mode
   • Full tuning capabilities
2. Vivid Ultimate DH RC2 (RS-VIVD-UDH-C1)
   • Downhill-specific configuration
   • RC2 compression damping
   • High and low speed compression adjustment
   • Racing-focused setup
3. Vivid Select+ RCT (RS-VIVD-SELP-C1)
   • Mid-range performance model
   • RCT compression damping
   • Threshold adjustment
   • Excellent value platform
4. Vivid Select RT (RS-VIVD-SEL-C1)
   • Performance trail model
   • RT compression damping
   • Rebound tuning
   • All-mountain applications
5. Vivid Base R (RS-VIVD-BSE-C1)
   • Entry-level platform
   • Reliable performance
   • Essential adjustment features
   • Cost-effective option

COMPREHENSIVE MANUAL CONTENTS:

SECTION 1: ROCKSHOX SERVICE FUNDAMENTALS

Essential service guidelines and safety:

• Safety First Protocols
  • Protective equipment requirements
  • Safety glasses and gloves mandatory
  • Crash hazard warnings
  • Proper handling procedures
• Part Preparation
  • Component removal from bicycle
  • Remote cable/hydraulic hose disconnection
  • Exterior cleaning procedures
  • Contamination prevention
• Service Procedures
  • RockShox Suspension Cleaner usage
  • Isopropyl alcohol cleaning methods
  • Sealing surface inspection
  • O-ring and seal replacement
  • Grease application techniques
  • Aluminum soft jaws for bench vise
  • Torque wrench procedures
  • Crowfoot socket installation
• • Serial number location
  • Product type identification
  • Platform/series designation
  • Model and version codesModel Code Identification
• Warranty and Trademark Information
  • SRAM warranty details
  • Trademark compliance
  • Service authorization

SECTION 2: RECOMMENDED SERVICE INTERVALS

Maintenance schedule for peak performance:

Every Ride:

• Clean dirt from shock damper body
• Wiper seal maintenance
• Benefits: Extends seal lifespan, minimizes damage, reduces friction

Every 100 Hours:

• Perform air can service
• Benefits: Reduces friction, restores small bump sensitivity

Every 200 Hours:

• Perform damper and spring service
• Benefits: Restores suspension performance, extends lifespan

Record Your Settings:

• Service date tracking
• Air pressure documentation
• Rebound setting recording
• Compression setting recording (high speed and low speed)

Torque Values:

• Complete torque specifications in N·m and in-lb
• Critical fastener torque requirements
• Proper tightening sequences

SECTION 3: PARTS, TOOLS, AND SUPPLIES

Comprehensive service requirements:

• Complete parts lists for all models
• Specialized RockShox service tools
• Service kit identification
• Lubricants and fluids specifications
• Optional upgrade kits
• Tool compatibility charts

SECTION 4: EXPLODED VIEW DIAGRAMS

Detailed illustrations for all models:

• 2024+ (C1) Vivid Ultimate RC2T (Page 8)
• 2024+ (C1) Vivid Ultimate DH RC2 (Page 9)
• 2024+ (C1) Vivid Select+ RCT (Page 10)
• 2024+ (C1) Vivid Select RT (Page 11)
• 2024+ (C1) Vivid Base R (Page 12)

Each diagram includes:

• Complete component identification
• Part numbers for ordering
• Assembly relationships
• Service kit compatibility

SECTION 5: SHOCK EYELET SERVICE – STANDARD EYELET

Complete eyelet maintenance procedures:

• Parts, Tools, and Supplies required
• Mounting Hardware Removal
  • Step-by-step disassembly
  • Proper tool usage
  • Component preservation
• Eyelet Bushing Removal
  • Extraction techniques
  • Damage prevention
  • Wear inspection
• Bushing Installation
  • Proper alignment
  • Press-fit procedures
  • Torque specifications
• Upgrade (Optional)
  • Standard eyelet to bearing adapter conversion
  • Installation procedures
  • Performance benefits

SECTION 6: SHOCK EYELET SERVICE – BEARING EYELET

Advanced bearing eyelet maintenance:

• Parts, Tools, and Supplies
• Bearing Removal – Shaft Eyelet
  • Specialized tool requirements
  • Extraction procedures
  • Bearing inspection criteria
• Bearing Installation – Shaft Eyelet
  • Press-fit techniques
  • Alignment procedures
  • Seal installation
• Damper Body Bearing Eyelet Assembly Replacement
  • Complete assembly procedures
  • Torque specifications

SECTION 7: AIR CAN SERVICE, AIR SPRING TUNING, AND RESERVOIR UPGRADE

100/200 Hour Service Procedures:

Air Can Removal:

• Detailed disassembly procedures
• Air release safety protocols
• Component preservation
• Cleaning requirements

Bottomless Tokens and Travel Reducers:

• Spring tuning system
• Token installation for progressive spring curves
• Travel reducer installation
• Tuning recommendations by rider weight/style
• Volume spacer configurations

Air Can and Sealhead Service:

• Internal cleaning procedures
• Seal replacement
• Lubrication specifications
• Reassembly techniques

Air Can Service – Sealhead Service:

• O-ring replacement
• Seal inspection
• Grease application
• Leak prevention

SECTION 8: DAMPER SERVICE AND RESERVOIR UPGRADE

200 Hour Service (Advanced Procedures):

Damper Service – Reservoir Disassembly:

• Complete teardown procedures
• Oil drainage
• Component separation
• Internal inspection

Damper Disassembly:

• Piston removal
• Shaft service
• Shim stack access
• Wear assessment

Upgrade (Optional) – Vivid C1 Ultimate RC2T Reservoir:

• Reservoir upgrade procedures
• Compatibility information
• Performance improvements
• Installation instructions

Damper Piston Service:

• Piston seal replacement
• Shim stack inspection
• Rebound circuit service
• Compression circuit service
• Wear limit inspection
• Cleaning and lubrication

Shock Assembly and Bleed:

• Critical assembly procedures
• Air purging techniques
• Bleed procedures
• Quality checks

Oil Fill and IFP Installation:

• Proper oil volumes
• Internal Floating Piston (IFP) setup
• Oil type specifications
• Contamination prevention

Damper Piston/Shaft/Eyelet Installation and Bleed:

• Complete assembly sequence
• Bleed procedures
• Shaft alignment
• Eyelet installation
• Final torque specifications

Remove Sealhead Compressor Tool:

• Tool removal procedures
• Final assembly steps
• Pressure testing

SECTION 9: AIR CAN SPRING TUNING AND INSTALLATION

100/200 Hour Service:

• Complete air spring installation
• Pressure setting procedures
• Sag adjustment guidelines
• Token configuration verification
• Travel adjustment confirmation
• Final assembly checks

SECTION 10: SHOCK EYELET SERVICE – MOUNTING HARDWARE

Standard Eyelet:

• Mounting Hardware Installation
• Proper torque sequences
• Thread preparation
• Final assembly

Bearing Eyelet:

• Damper Body Bearing Eyelet Installation
• Bearing press procedures
• Alignment verification
• Mounting hardware installation

SECTION 11: SHOCK INSTALLATION AND SETUP

Final installation and tuning:

• Shock installation on bicycle frame
• Mounting hardware torque specifications
• Initial air pressure setup
• Sag measurement procedures
• Rebound adjustment
• Compression adjustment (model-specific):
  • Threshold (pedal) mode setup
  • Low speed compression tuning
  • High speed compression tuning
• Ride height verification
• Final safety checks

KEY TECHNICAL FEATURES:

Service Coverage: ✓ 100-hour air can service – Seal replacement and cleaning
✓ 200-hour damper service – Complete rebuild and oil change
✓ Eyelet service – Both standard bushing and bearing types
✓ Spring tuning – Bottomless tokens and travel reducers
✓ Reservoir upgrade – Ultimate RC2T upgrade path
✓ Bleed procedures – Professional-grade damper servicing

Adjustment Systems Covered: ✓ Rebound damping adjustment
✓ Low speed compression damping
✓ High speed compression damping
✓ Threshold (pedal) mode adjustment
✓ Air spring pressure tuning
✓ Progressive spring curves via tokens

Who Needs This Manual:

✓ Professional Bicycle Mechanics servicing suspension systems
✓ Bike Shop Service Departments performing warranty work
✓ RockShox Authorized Service Centers conducting official repairs
✓ Advanced Home Mechanics with proper tools and experience
✓ Mountain Bike Racing Teams maintaining team equipment
✓ Downhill Bike Mechanics servicing DH race bikes
✓ Enduro Racing Support for competitive maintenance
✓ Bike Park Rental Fleets managing high-use equipment
✓ Suspension Tuning Specialists optimizing shock performance

What Makes This Manual Essential:

• Official SRAM/RockShox documentation – Factory-authorized procedures
• Five model coverage – All 2024+ Vivid variants in one manual
• 113 comprehensive pages with detailed photographs
• Step-by-step procedures for all service intervals
• Exploded view diagrams with part numbers for ordering
• Specialized tool requirements clearly identified
• Torque specifications for all critical fasteners
• Upgrade paths documented – Ultimate RC2T reservoir conversion
• Spring tuning guidance – Bottomless token configurations
• Professional bleed procedures for optimal damper performance
• Safety warnings throughout to prevent injury and damage
• Spare parts catalog integration for easy part identification

Critical Service Information:

Required Specialized Tools:

• RockShox-specific service tools
• Sealhead compressor tool
• Bearing press tools
• Torque wrenches
• Shock vise tools

Required Lubricants/Fluids:

• RockShox Suspension Cleaner
• Specific suspension oils
• Specialty greases
• Seal lubricants

Warranty Compliance:

• Proper service maintains warranty
• Authorized procedures only
• Genuine RockShox parts required
• Service interval adherence important

Performance Applications:

Bike Types:

• Downhill (DH) racing bikes
• Enduro mountain bikes
• All-mountain bikes
• Freeride bicycles
• Aggressive trail bikes
• Bike park bikes

Riding Styles:

• Competitive downhill racing
• Enduro racing
• Technical trail riding
• Jump/freeride
• Bike park riding
• Aggressive all-mountain

Professional suspension service resource! This official RockShox service manual is absolutely essential for anyone servicing 2024+ Vivid rear shocks. Download instantly and access factory-authorized procedures, complete rebuild instructions, spring tuning guidance, and upgrade paths. Maintain your high-performance suspension at peak performance with proper 100-hour and 200-hour service procedures. Includes specialized techniques for damper bleeding, IFP installation, and shim stack service that ensure optimal small bump sensitivity and control.
