Kverneland Taarup 4228LT Mower Parts Manual – PDF DOWNLOAD

Description

Kverneland Taarup 4228LT Mower Parts Manual – PDF DOWNLOAD

FILE DETAILS:

Kverneland Taarup 4228LT Mower Parts Manual – PDF DOWNLOAD

Language : English
Pages : 49
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:

TABLE OF CONTENTS:

Kverneland Taarup 4228LT Mower Parts Manual – PDF DOWNLOAD

Article number: 90.000.130 Index 116-07
Language: EN
Production year (from): 2006
Serial No. (from) 395.344 < Mach. ID <=

1 PRIMARY FRAME, WHEEL 1
2 CONNECTING ARM 2
2 SPRING, HYDRAULIC CYLINDER 3
3 DRAWBAR 4
4 SWIVEL GEAR, COMPLETE 5
5 HYDRAULIC 6
5 HYDRAULIC, DRAWBAR 7
6 PRIMARY FRAME 8
7 TRANSMISSION 9
8 CONDITIONER PLATE 10
9 ROTOR 11
10 MAIN GEAR BOX 12
11 CUTTERBAR 1 13
11 TRANSMISSION, CUTTERBAR 14
11 CUTTERBAR 2 15
12 GUARD 1 16
12 GUARD 2 17
12 REAR END & DEFLECTOR PLATE 18
13 PTO SHAFT 1 19
14 PTO SHAFT 2 20
