Audi A4 (2007–2016) / A5 Cabriolet / A5 Coupé 1.8 L & 2.0 L TFSI Gen III Engine Workshop Manual
$37.95
Factory Audi A4 (2007–2016) / A5 (Coupé & Cabriolet) 1.8L & 2.0L TFSI Engine Workshop Manual – official Edition 10.2014 PDF.
Includes full engine teardown, turbocharger service, lubrication & cooling diagrams, torque specs, and all Gen III TFSI repair procedures.
Description
The Audi A4 (2007–2016) and A5 (Coupé / Cabriolet) 1.8L & 2.0L TFSI Engine Workshop Manual (Edition 10.2014) provides complete factory instructions for servicing, rebuilding, and maintaining the Generation III TFSI engines (engine codes CJEB, CNCD, CUHA, CUJA, CJED).
This official factory service manual includes step-by-step repair procedures, torque settings, and illustrated diagrams for all engine subsystems — ideal for professional workshops and enthusiasts.
IMAGES:
Repair Groups Included
| Group | System / Component |
|---|---|
| 00 | Technical data & safety precautions |
| 10 | Engine removal / installation |
| 13 | Crankshaft group – block, bearings, balance shaft |
| 15 | Cylinder head / valve gear / timing chain |
| 17 | Lubrication – oil pump, cooler, filters |
| 19 | Cooling system – pump, thermostat, radiator |
| 21 | Turbocharging / supercharging |
| 24 | Mixture preparation / injection system |
| 26 | Exhaust system / catalyst |
| 28 | Ignition system and sensors |
Engine Data (TFSI Gen III)
| Engine Code | Displacement (L) | Power (kW / rpm) | Torque (Nm / rpm) | Bore × Stroke (mm) | Compression |
|---|---|---|---|---|---|
| CJEB | 1.8 | 125 / 3800–6200 | 320 / 1400–3700 | 82.5 × 84.1 | 9.6 : 1 |
| CNCD | 2.0 | 165 / 4500–6200 | 350 / 1500–4500 | 82.5 × 92.8 | 9.6 : 1 |
| CUHA | 2.0 | 165 / 4800–6200 | 350 / 1500–4750 | 82.5 × 92.8 | 9.6 : 1 |
| CUJA | 1.8 | 132 / 4000–6200 | 320 / 1500–4750 | 82.5 × 84.1 | 9.6 : 1 |
| CJED | 1.8 | 106 / 3700–6200 | 280 / 1300–3600 | 82.5 × 84.1 | 9.6 : 1 |
All variants feature direct fuel injection (TFSI), variable valve timing, and turbocharging.
Fuel: RON 95 recommended; no EGR or secondary air system.
Key Procedures Covered
Engine Removal / Installation – mount points, subframe handling, and battery precautions.
Crankshaft & Balance Shafts – bearing selection, clearance checks, torque charts.
Cylinder Head & Valve Gear – timing chain setup, camshaft installation, valve testing.
Lubrication System – oil pump drive, oil cooler service, pressure testing.
Cooling System – draining, refilling, and sender location diagrams.
Turbocharging – exploded views, intercooler removal, and leak test instructions.
Fuel Injection System – fuel rail and injector installation, pressure reduction steps.
Ignition System – coil pack servicing and knock sensor replacement (G28).
Safety & Workshop Notes
De-pressurize the high-pressure fuel system before disconnecting lines.
Cover coolant cap with a cloth to prevent burns from steam.
Switch off ignition before removing connectors or battery terminals.
Secure vehicle before engine removal to prevent tipping.
🧰 Includes factory tool references: VAS 6122, T10337, VAS 6213, etc.
🧾 File Details
Document No.: Workshop Manual Edition 10.2014
Models Covered: Audi A4 (2007–2016), A5 Cabriolet (2009– ), A5 Coupé (2008– )
Engine Codes: CJEB, CNCD, CUHA, CUJA, CJED (1.8 / 2.0 TFSI)
Drive / Transmission: Manual & Multitronic FWD / Quattro
Pages: ≈ 300+
Format: Searchable PDF (OCR-enabled)
Language: English
File Size: ≈ 75 MB
Quality Notes: High-resolution factory scan with clickable bookmarks and diagrams.
✅ Verified factory manual for Audi TFSI Gen III engines
💾 Instant download – lifetime access
🔍 Perfect for workshop diagnostics, rebuilds, and maintenance
