AWT E1070 Indicator Service Manual – Revision 2006 (PDF)

Description

AWT E1070 Indicator Service Manual – Revision 2006 (PDF) DOWNLOAD

Description

Overview

The AWT E1070 Indicator Service Manual (Rev. 2006) is a detailed factory manual providing configuration, calibration, diagnostics, and maintenance procedures for the E1070 weighing indicator. It covers both analog and SensorComm systems, serial communications (RS-232/422/485, DeviceNet, Profibus, Ethernet/IP), and internal setup menus with full step-by-step instructions.

⚙️ Specifications Highlights

• Power: 85–265 VAC, 50/60 Hz, 0.3 A max

• Excitation: ±5 VDC (up to 8 × 350 Ω load cells)

• Analog Input: ±60 mV range

• A/D Conversion Rate: 100 Hz

• Display: 6-digit LED, 0.8-inch height

• Enclosure: Stainless steel NEMA 6/4X

• Outputs: Ethernet (Modbus/TCP, SMTP, DHCP, Ethernet/IP), Profibus DP, DeviceNet, 3 cutoff outputs

• Inputs: 3 logic-level inputs (Zero, Print, Tare, etc.)

• Operating Temp: –10 °C to 40 °C approved (–40 °C to 60 °C non-legal)

  520334320-AWT-E1070-rev2006-Ser…

📖 Table of Contents Overview

• Introduction & Front Panel Layout – key functions, annunciators, and safety.

• Error Messages – overrange, underrange, calibration entry errors.

• Menu Navigation – password-protected User (111), Service (0701), and Supervisor (1793) menus.

• User Menu – testing display, buttons, serial ports, viewing configuration & calibration counters.

• Service Menu

  • CAL submenu – analog zero/span calibration, 2–5-point linearization, input calibration, live display & calibration printout.

  • SCALE submenu – capacity, division, decimal point, units (lb/kg/custom), stability, auto-zero tracking, tare setup, filter constants.

  • APP submenu – application enable/disable (Accumulator, Batch, Count, Target, Peak Hold, General, Remote Display).

  • SERIAL submenu – full port configuration (baud rate, parity, handshake, protocol: ENQ, Broadcast, SMA, Remote Display).

• Supervisor Menu – date/time setup, test modes, audit counters, recipes, and sample modes.

• SensorComm Hardware Calibration – corner/ghost calibration, weigh-bar configuration, network LED diagnostics.

• Appendices – Remote display functionality, LED diagnostics, network connection diagrams, complete menu map, and technical illustrations.

🧰 Technical Features

• Advanced digital filtering (Harmonizer™) for vibration & noise.

• Five-point linearization for accuracy.

• Custom print formats using hexadecimal string editing.

• Supports multiple communication interfaces:

  • Ethernet/IP, Modbus/TCP, Profibus, DeviceNet, RS-232/422/485.

• Fully programmable print labels for thermal or dot-matrix printers (formats 1–15).

• Self-diagnostic tools for keys, display, A/D converter, serial ports.

• Compatible applications: weighing, accumulation, batching, counting, checkweighing, peak, and remote display operation.

🔍 Diagnostic & Calibration Functions

• Real-time ADC mV/V display

• Button and serial loopback tests

• Configuration & calibration audit counters (non-resettable)

• SensorComm ghost calibration & error logs

• Optional analog output, pulse input, or remote foot control modules

📦 File Details

💡 Why Buy This Manual

• Provides step-by-step calibration & service guidance for both analog and SensorComm installations.

• Includes complete menu flowcharts, eliminating guesswork during configuration.

• Saves time on field troubleshooting with defined error messages and serial protocol references.

• Covers network, communication, and print setup, which generic operation manuals omit.
