BOBCAT 3PT Rotary Cutter 48 60 72 Operation & Maintenance Manual 7383796 PDF DOWNLOAD
$19.95
BOBCAT 3PT Rotary Cutter 48 60 72 Operation & Maintenance Manual 7383796 PDF DOWNLOAD
(48) S/N B4UN00101 & Above
(60) S/N B4UM00101 & Above
(72) S/N B4UP00101 & Above
Description
BOBCAT 3PT Rotary Cutter 48 60 72 Operation & Maintenance Manual 7383796 PDF DOWNLOAD
FILE DETAILS:
BOBCAT 3PT Rotary Cutter 48 60 72 Operation & Maintenance Manual 7383796 PDF DOWNLOAD
Language : English
Pages : 80
Downloadable : Yes
File Type : PDF
IMAGES PREVIEW OF THE MANUAL:
TABLE OF CONTENTS:
BOBCAT 3PT Rotary Cutter 48 60 72 Operation & Maintenance Manual 7383796 PDF DOWNLOAD
(48) S/N B4UN00101 & Above
(60) S/N B4UM00101 & Above
(72) S/N B4UP00101 & Above
OPERATOR SAFETY WARNINGS……………………………………. 3
CONTENTS………………………………………………….. 5
FOREWORD………………………………………………….. 7
BOBCAT COMPANY IS IS0 9001 CERTIFIED……………………… 9
SERIAL NUMBER LOCATION…………………………………..11
Implement Serial Number………………………………11
DELIVERY REPORT…………………………………………11
IMPLEMENT IDENTIFICATION…………………………………12
FEATURES AND ACCESSORIES…………………………………13
Standard Items………………………………………13
SAFETY & TRAINING RESOURCES………………………………….15
SAFETY INSTRUCTIONS……………………………………..17
Safe Operation Is The Operator’s Responsibility…………17
Safe Operation Needs A Qualified Operator………………17
Use Safety Rules…………………………………….18
Call Before You Dig………………………………….18
Avoid Silica Dust……………………………………18
Safety Rules For Power Take-Off (PTO) Driven Implements….19
Compact Tractor Requirements And Capabilities…………..19
FIRE PREVENTION…………………………………………20
Maintenance…………………………………………20
Operation…………………………………………..20
Electrical………………………………………….20
Hydraulic System…………………………………….20
Fueling…………………………………………….20
Starting……………………………………………20
Spark Arrester Exhaust System…………………………20
Welding And Grinding…………………………………21
Fire Extinguishers…………………………………..21
PUBLICATIONS AND TRAINING RESOURCES……………………….22
IMPLEMENT SIGNS (DECALS)…………………………………23
OPERATING INSTRUCTIONS………………………………………25
DAILY INSPECTION………………………………………..27
Implement Mounting Frame……………………………..27
Three-Point Hitch……………………………………27
OPERATING PROCEDURE WITH COMPACT TRACTORS………………….28
Approved Compact Tractor Models And Requirements………..28
Compact Tractor / Implement Setup……………………..28
Entering And Exiting The Compact Tractor……………….31
Installation………………………………………..32
Rear Power Take-Off (PTO)…………………………….36
Control Functions Three-Point Hitch (Implement)…………42
Control Functions Rear-PTO……………………………42
Control Functions Three-Point Hitch (Implement)…………44
Operation With The Compact Tractor…………………….44
Removal…………………………………………….46
LIFTING THE IMPLEMENT……………………………………48
Procedure…………………………………………..48
TRANSPORTING THE IMPLEMENT ON A TRAILER……………………48
Fastening…………………………………………..48
TRANSPORTING THE IMPLEMENT AND MACHINE ON A TRAILER…………49
Loading And Fastening………………………………..49
PREVENTIVE MAINTENANCE………………………………………51
MAINTENANCE SAFETY………………………………………53
TROUBLESHOOTING…………………………………………55
Chart………………………………………………55
SERVICE SCHEDULE………………………………………..56
REGULAR MAINTENANCE ITEMS………………………………..57
Gear Box Fluid………………………………………57
Cleaning The Three-Point Rotary Cutter…………………57
LUBRICATING THE IMPLEMENT………………………………..58
Lubrication Locations………………………………..58
CUTTING BLADES………………………………………….59
Removal And Installation……………………………..59
SHEAR BOLT……………………………………………..61
Removal And Installation……………………………..61
IMPLEMENT STORAGE AND RETURN TO SERVICE……………………62
Storage…………………………………………….62
Return To Service……………………………………62
MACHINE SIGN TRANSLATIONS……………………………………63
MACHINE SIGN TRANSLATIONS………………………………..65
Service Schedule (7139186)……………………………65
Warning (6734440)……………………………………66
Warning (7139187)……………………………………67
Warning (7163177)……………………………………68
SPECIFICATIONS……………………………………………..69
THREE-POINT ROTARY CUTTER SPECIFICATIONS…………………..71
Dimensions………………………………………….71
WARRANTY…………………………………………………..73
WARRANTY……………………………………………….75
ALPHABETICAL INDEX………………………………………….77
