Bobcat 843 Loader Operation & Maintenance Manual SN 502620001 & Above – PDF DOWNLOAD

Description

Bobcat 843 Loader Operation & Maintenance Manual SN 502620001 & Above – PDF DOWNLOAD

FILE DETAILS:

Bobcat 843 Loader Operation & Maintenance Manual SN 502620001 & Above – PDF DOWNLOAD

Language : English
Pages : 96
Downloadable : Yes
File Type : PDF

TABLE OF CONTENTS:

Bobcat 843 Loader Operation & Maintenance Manual SN 502620001 & Above – PDF DOWNLOAD

OPERATOR SAFETY WARNINGS 3
CONTENTS 5
FOREWORD 7
SERIAL NUMBER LOCATIONS 9
LOADER SERIAL NUMBER 9
ENGINE SERIAL NUMBER 9
DELIVERY REPORT 9
BOBCAT LOADER IDENTIFICATION 10
SAFETY 11
SAFETY INSTRUCTIONS 13
Safety Is The Operator’s Responsibility 13
Before Operating The Bobcat Loader 14
Safe Operation Needs A Qualified Operator 14
FIRE PREVENTION 15
OPERATING INSTRUCTIONS 17
OPERATING INSTRUCTIONS 19
GETTING ON AND OFF THE LOADER 19
SAFETY SIGNS (DECALS) 20
LEARNING THE CONTROLS 20
DASH PANEL 23
THROTTLE CONTROL 23
PARKING BRAKE 23
STEERING LEVERS 24
HYDRAULIC CONTROLS 25
Left Foot Pedal / Lift Arm Operation 25
Left Foot Pedal / Float Position For the Lift Arms 25
Right Foot Pedal / Tilt (Bucket) Operation 25
Right Lever / Auxiliary Operation 26
BEFORE STARTING THE ENGINE 26
STARTING THE ENGINE 28
Cold Temperature Starting 29
ATTACHMENTS & BUCKETS 30
Bucket Or Fork Installation 31
Bucket Or Fork Removal 31
OPERATING PROCEDURES 32
Filling The Bucket 33
Emptying The Bucket 33
Digging Into The Ground 34
Leveling The Ground (Using Float Position For The Lift Arms) 34
Backfilling 35
PARKING THE LOADER 35
TOWING THE LOADER 35
TRANSPORTING THE LOADER 35
LIFTING THE LOADER 36
PREVENTIVE MAINTENANCE 37
MAINTENANCE SAFETY 39
SERVICE SCHEDULE 41
LIFT ARM STOP 42
OPERATOR CAB 42
Raising The Operator Cab 43
Lowering The Operator Cab 43
SEAT BAR SYSTEM 43
Inspection Of The Seat Bar System 44
Service Of The Seat Bar System 44
REAR DOOR 44
Door Latch Adjustment 45
AIR CLEANER 45
FUEL SYSTEM 46
Filling The Fuel Tank 46
Fuel Filter 47
Removing Air From The Fuel System 48
ENGINE LUBRICATION SYSTEM 49
Engine Oil And Filter Replacement 49
COOLING SYSTEM 50
Coolant Level 50
Coolant Replacement 50
Cooling System Maintenance 50
ALTERNATOR BELT ADJUSTMENT 51
ELECTRICAL SYSTEM 54
Electrical System Service 54
Using An Extra Battery (Jump Starting) 54
Battery Replacement 56
HYDRAULIC / HYDROSTATIC SYSTEM 56
Hydraulic / Hydrostatic Fluid Reservoir 56
Checking And Adding Fluid 56
Hydraulic Fluid Replacement 58
Hydraulic (10 Micron) Filter Replacement 58
Hydrostatic (#3 Element) Filter Replacement 59
SPARK ARRESTOR MUFFLER 60
FINAL DRIVE TRANSMISSION (CHAINCASE) 60
Chaincase Fluid Level 60
TIRE MAINTENANCE 61
Tire Rotation 61
Wheel Nuts 61
LOADER LUBRICATION 62
BOB-TACH 63
PIVOT PINS 63
BRAKE PEDAL ADJUSTMENT 63
TROUBLESHOOTING 65
TROUBLESHOOTING THE ENGINE 67
TROUBLESHOOTING THE DRIVE SYSTEM 68
TROUBLESHOOTING THE HYDRAULIC SYSTEM 69
MAJOR PARTS 71
MAIN FRAME 73
PANELS, SEAT, SEAT BAR & FUEL SYSTEM 74
DRIVE SYSTEM 75
HYDRAULIC SYSTEM 76
HYDROSTATIC SYSTEM 77
HAND CONTROLS AND CONTROL PEDALS 78
OPERATOR CAB ELECTRICAL SYSTEM 79
ENGINE ELECTRICAL 80
ENGINE & ATTACHING PARTS 81
SAFETY SIGNS 83
WARNING – 6565980 85
SERVICE SCHEDULE – 6567875 86
WARNING – 6568692 88
WARNING – 6568691 89
IMPORTANT – 6560573 90
SPECIFICATIONS 91
OPERATION AND PERFORMANCE 93
ENGINE 93
HYDRAULIC SYSTEM 94
ELECTRICAL 94
DRIVE SYSTEM 94
CAPACITIES 94
TIRES 94
WARRANTY 95

DESCRIPTION:

Bobcat 843 Loader Operation & Maintenance Manual SN 502620001 & Above – PDF DOWNLOAD

FOREWORD:

This Operation & Maintenance Manual was written to give the owner/operator instructions on the safe operation and maintenance of the Bobcat loader. READ AND UNDERSTAND THIS OPERATION & MAINTENANCE MANUAL BEFORE OPERATING YOUR LOADER. If you have any questions, see your Bobcat loader dealer.

SAFETY INSTRUCTIONS:
SAFETY IS THE OPERATOR’S RESPONSIBILITY:

• The Skid Steer Loader is a highly maneuverable and compact machine. In operation, it is rugged and useful under a wide variety of conditions. This presents an operator with hazards associated with off highway, rough terrain applications. The loader has an internal combustion engine with resultant heat and exhaust. All exhaust gases can kill or cause illness so the loader must be used with adequate ventilation. The loader has a spark arrestor muffler which is required for operation in certain areas.
• The dealer explains the capabilities and restrictions of the loader and attachments for each application. The dealer
  demonstrates the safe operation of the loader according to Melroe’s instructional materials; which are also available to operators. The dealer can also identify unsafe modifications or use of unapproved attachments. The attachments and buckets are designed for rated capacity and secure fastening to the loader. The user must check with the dealer, or Melroe Company literature, to determine safe loads of materials of specified densities for his loader–attachment combination.

The following publications provide information on the safe use and maintenance of the loader and attachments:
• The Delivery Report is used to assure that complete instructions have been given to the new owner and that the machine
is in safe operating condition.
• The Operation & Maintenance Manual delivered with the loader gives operating information as well as routine
maintenance and service procedures. It is a part of the loader and must stay with the machine when it is sold.
Replacement Operation & Maintenance Manuals can be ordered from your Bobcat loader dealer.
• The loader has machine signs (decals) which instruct on the safe operation and care. The signs and their locations are
shown in the Operation & Maintenance Manual. Replacement signs are available from your Bobcat loader dealer.
• The loader has a plastic Operator’s Handbook fastened to the operator cab. Its brief instructions are convenient to the
operator. The handbook is available from your dealer in English edition or a combination English, French, German,
Italian, Dutch & Spanish edition.
• The EMI Safety Manual (available in Spanish) delivered with the loader gives general safety information.
• The Service Manual and Parts Manual are available from your dealer for use by mechanics to do shop–type service and
repair work.
• The Skid–Steer Loader Operator Training Course is available through your local dealer. This course is intended to
provide rules and practices for correct operation of the Bobcat loader. The course is available in English and Spanish
version.
• The Bobcat Skid–Steer Loader Safety Video is available from your Bobcat Dealer.
The dealer and owner/operator review the recommended uses of the loader and attachments when the loader is delivered.
If the owner/operator will be using the loader for a different application(s) he must ask the dealer for recommendations on
the new use.

Customer Support: [email protected]
