Bobcat E10 Compact Excavator Service Manual PDF Download
Original price was: $90.00.$31.95Current price is: $31.95.
Factory-issued Bobcat E10 Compact Excavator Service Manual with complete maintenance, hydraulic, electrical, and engine repair data. Includes wiring schematics, torque specs, troubleshooting charts, and service intervals.
Description
Bobcat E10 Compact Excavator Service Manual β Hydraulic, Electrical & Engine Repair PDF Download
IMAGES:

π BOOKMARKS / TABLE OF CONTENTSΒ
Bobcat E10 Compact Excavator Service Manual (6986788-enUS)
MAINTENANCE SAFETY
ββ’ Precautions for service personnel
ββ’ Lockout/tagout procedures
ββ’ Fluid handling and fire preventionCONTENTS & FOREWORD
ββ’ Manual organization and how to use this book
ββ’ Metric/US conversion dataSAFETY AND MAINTENANCE
ββ’ Safety signs, decals, and warnings
ββ’ Machine preparation, lifting, and jacking points
ββ’ Preventive maintenance chart and fluid replacement intervalsHYDRAULIC SYSTEM
ββ’ System overview and flow diagram
ββ’ Main control valve, pilot lines, and boom/arm/bucket cylinders
ββ’ Testing and adjusting main relief valve
ββ’ Hydraulic oil, filter, and hose specificationsUNDERCARRIAGE
ββ’ Track frame and sprocket assembly
ββ’ Track tensioning and idler servicing
ββ’ Drive motor removal and installationUPPERSTRUCTURE & SWING SECTION
ββ’ Swing bearing torque sequence
ββ’ Slew motor inspection
ββ’ Boom and arm pin bushing clearancesELECTRICAL SYSTEM & ANALYSIS
ββ’ Battery, starter, and alternator testing
ββ’ Complete wiring schematic and connector chart
ββ’ Fuse and relay layout
ββ’ Controller diagnostic proceduresENGINE SERVICE
ββ’ Kubota D722 engine data and tune-up specs
ββ’ Oil and filter replacement procedure
ββ’ Valve clearance adjustment
ββ’ Cooling system bleeding
ββ’ Fuel injection timing adjustmentSPECIFICATIONS
ββ’ Engine, hydraulic, and torque specifications
ββ’ Capacities and performance data
ββ’ Standard torque chart (M6βM20)ALPHABETICAL INDEX
ββ’ Indexed by system for fast lookupSERVICE SCHEDULE SYMBOLS
ββ’ Maintenance frequency guide
ββ’ Component service indicators
Β PRODUCT DESCRIPTION
The Bobcat E10 Compact Excavator Service Manual (Publication No. 6986788-enUS) is the official factory manual designed for workshop technicians and equipment owners responsible for maintaining and repairing the Bobcat E10 mini excavator.
This PDF manual delivers comprehensive details for mechanical, hydraulic, electrical, and engine systems, including component testing, adjustment procedures, and troubleshooting charts.
βοΈ Mechanical and Engine Systems
This manual covers the Kubota D722 3-cylinder diesel engine, with full service instructions for oil pump, governor, cooling fan, and fuel injection system. It provides step-by-step valve adjustment procedures, head gasket replacement, and compression testing data for precise servicing.
π§ Hydraulic and Power Systems
The hydraulic section features detailed diagrams for boom, arm, bucket, and swing functions. Flow tests, pilot line diagnostics, and cylinder disassembly procedures are clearly illustrated. Relief valve testing, oil contamination checks, and hydraulic motor removal are also described.
β‘ Electrical System
Includes wiring schematics for the starting, charging, and safety interlock systems, plus connector pinouts and voltage testing methods. Youβll find fault diagnosis steps for sensor circuits and battery drain conditions.
π οΈ Maintenance & Preventive Service
Maintenance charts list daily, 50-hour, 250-hour, and 1000-hour service intervals. Each section provides inspection points, torque settings, lubrication specifications, and component replacement intervals to ensure reliable field operation.
π Specifications
Technical data tables summarize torque specs, hydraulic pressures, tightening sequences, and electrical values for rapid workshop reference.
π Why This Manual?
Genuine Bobcat-authorized content β identical to dealer workshop guides
Fully searchable, printable PDF format
Contains exploded views, diagrams, and complete torque data
Ideal for mechanics, rental fleets, and workshop technicians
This service manual is indispensable for any owner or technician seeking accurate repair procedures and diagnostic support for the Bobcat E10 Compact Excavator.
βοΈ FILE DETAILS
| Field | Information |
|---|---|
| Manual Title | Bobcat E10 Compact Excavator Service Manual |
| Manufacturer | Bobcat Company |
| Publication No. | 6986788-enUS |
| Models Covered | Bobcat E10 Compact Excavator |
| Machine Type | Compact Excavator / Mini Digger |
| Engine Model | Kubota D722-E3B, 3-Cylinder Diesel |
| Displacement | 0.719 L (719 cc) |
| Rated Power | 7.4 kW (10.0 HP) @ 2200 rpm |
| Operating Weight | 1176 kg (2592 lb) |
| Hydraulic System Pressure | 210 bar (3045 psi) |
| Hydraulic Flow Rate | 22 L/min |
| Travel Speed | 2.1 km/h (low) β 3.1 km/h (high) |
| Fuel Tank Capacity | 19 L |
| Cooling System Capacity | 3.6 L |
| Lubricating Oil Capacity | 2.8 L |
| Electrical System | 12V DC, 40A Alternator |
| Publication Type | Factory Service & Maintenance Manual |
| Language | English |
| File Format | Searchable PDF |
| Pages | 698 pages |
| File Size | ~21.8MB |
| Includes | Maintenance, Hydraulic, Electrical, Engine, Specifications, Troubleshooting |
| Applicable Years | 2012β2022 (E10 Series) |
| Publisher Location | West Fargo, ND, USA |
