Bobcat Utility Blade 54 Operation & Maintenance Manual SN APHL00101 & Above – PDF DOWNLOAD

FILE DETAILS:

Bobcat Utility Blade 54 Operation & Maintenance Manual SN APHL00101 & Above – PDF DOWNLOAD

Language : English
Pages :96
Downloadable : Yes
File Type : PDF

TABLE OF CONTENTS:

Bobcat Utility Blade 54 Operation & Maintenance Manual SN APHL00101 & Above – PDF DOWNLOAD

CONTENTS 3
FOREWORD 5
DECLARATION OF CONFORMITY 7
BOBCAT COMPANY IS IS0 9001 CERTIFIED 9
SERIAL NUMBER LOCATION 11
Attachment Serial Number 11
DELIVERY REPORT 11
ATTACHMENT IDENTIFICATION 12
FEATURES AND ACCESSORIES 13
Standard Items 13
Options And Accessories 13
SAFETY AND TRAINING RESOURCES 15
SAFETY INSTRUCTIONS 17
Safe Operation Is The Operator’s Responsibility 17
Safe Operation Needs A Qualified Operator 17
Use Safety Rules 18
Avoid Silica Dust 18
FIRE PREVENTION 19
Maintenance 19
Operation 19
Electrical 19
Hydraulic System 19
Fueling 19
Starting 19
Spark Arrester Exhaust System 19
Welding And Grinding 20
Fire Extinguishers 20
PUBLICATIONS AND TRAINING RESOURCES 21
ATTACHMENT SIGNS (DECALS) 22
Pictorial Only Safety Signs 23
OPERATING INSTRUCTIONS 25
INITIAL SETUP 27
Adjusting Skid Shoe Height 27
DAILY INSPECTION 28
Attachment Mounting Frame 28
Bob-Tach 29
OPERATING PROCEDURE WITH LOADERS 30
Approved Loader Models And Requirements 30
Entering And Exiting The Loader 31
Installation 33
Hydraulic Quick Couplers 37
Control Functions 38
Operation With The Loader 39
Removal 41
OPERATING PROCEDURE WITH MINI TRACK LOADERS 43
Approved Mini Track Loader Models And Requirements 43
Entering And Leaving The Operator’s Position 44
Installation 45
Hydraulic Quick Couplers 49
Control Functions 50
Operation With The Mini Track Loader 51
Removal 53
LIFTING THE ATTACHMENT 54
Procedure 54
TRANSPORTING THE ATTACHMENT ON A TRAILER 55
Fastening 55
TRANSPORTING THE ATTACHMENT AND MACHINE ON A TRAILER 56
Loading And Fastening 56
PREVENTIVE MAINTENANCE 57
TROUBLESHOOTING 61
Chart 61
REMOVAL AND INSTALLATION OF TRIP SPRINGS 62
Procedure 62
REMOVAL AND INSTALLATION OF SKID SHOE 64
Procedure 64
REMOVAL AND INSTALLATION OF CUTTING EDGE 65
Procedure 65
REMOVAL AND INSTALLATION OF HYDRAULIC CYLINDER 66
Procedure 66
HYDRAULIC CYLINDER 68
Parts Identification 68
Disassembly 69
Assembly 72
ATTACHMENT STORAGE AND RETURN TO SERVICE 77
Storage 77
Return To Service 77
SPECIFICATIONS 79
SCHEMATIC 81
Hydraulic Schematic 81
HYDRAULIC CYLINDER 82
Torque Specifications 82
Torque Chart 82
UTILITY BLADE SPECIFICATIONS 83
Dimension 83
Performance 83
TORQUE SPECIFICATIONS FOR BOLTS 84
Torque For General SAE Bolts 84
Torque For General Metric Bolts 85
HYDRAULIC CONNECTION SPECIFICATIONS 86
O-ring Face Seal Connection 86
Straight Thread O-ring Fitting 86
Tubelines And Hoses 86
Flare Fitting 87
Port Seal Fitting 87
WARRANTY 89
WARRANTY 91
ALPHABETICAL INDEX 93

IMAGES PREVIEW OF THE MANUAL:

DESCRIPTION:

Bobcat Utility Blade 54 Operation & Maintenance Manual SN APHL00101 & Above – PDF DOWNLOAD

FOREWORD

This Operation & Maintenance Manual was written to give the owner / operator instructions on the safe operation and maintenance of the Bobcat utility blade. READ AND UNDERSTAND THIS OPERATION & MAINTENANCE MANUAL BEFORE OPERATING YOUR BOBCAT UTILITY BLADE. If you have any questions, see your Bobcat dealer.

SAFETY INSTRUCTIONS

Operator must have instructions before operating the machine. Untrained operators can cause injury or death.

Safe Operation Needs A Qualified Operator

For an operator to be qualified, he or she must not use drugs or alcoholic drinks which impair alertness or coordination while working. An operator who is taking prescription drugs must get medical advice to determine if he or she can safely operate a machine and the attachment.

A Qualified Operator Must Do The Following:

Understand the Written Instructions, Rules and Regulations

• The written instructions from Bobcat Company include the Delivery Report, Operation & Maintenance Manual, Operator’s Handbook, Safety Manual and machine signs (decals).
• Check the rules and regulations at your location. The rules may include an employer’s work safety requirements. Regulations may apply to local driving requirements or use of a Slow Moving Vehicle (SMV) emblem. Regulations may identify a hazard such as a utility line.

Have Training with Actual Operation

•  Operator training must consist of a demonstration and verbal instruction. This training is given by your Bobcat dealer before the product is delivered.
• The new operator must start in an area without bystanders and use all the controls until he or she can operate the machine and attachment safely under all conditions of the work area. Always fasten seat belt before operating.

Know the Work Conditions

• Know the weight of the materials being handled. Avoid exceeding the machine load capacities. Material which is very dense will be heavier than the same volume of less dense material. Reduce the size of load if handling dense material.
• The operator must know any prohibited uses or work areas, for example, he or she needs to know about excessive slopes.
• Know the location of any underground lines. Call local utilities or the TOLL FREE phone number found in the Call Before You Dig section of this manual.
• Wear tight fitting clothing. Always wear safety glasses when doing maintenance or service. Safety glasses, respiratory equipment, and hearing protection are required for some work. See your Bobcat dealer about Bobcat safety equipment for your machine.

SAFETY INSTRUCTIONS (CONT’D)
Use Safety Rules

• Read and follow instructions in the machine and the attachment’s / implement’s Operation & Maintenance Manual before operating.
• Check for underground lines before operating attachment / implement (if applicable).
• In addition to the design and configuration of equipment, hazard control and accident prevention are dependent upon the awareness, concern, prudence and proper training of personnel involved in the operation, transport, maintenance and storage of equipment.
• Check that the attachment mounting pins and hardware are installed correctly and securely fastened (if equipped).
• Check that the loader is securely installed to the compact tractor using the correct pins and hardware.
• Check that the Bob-Tach® levers are in the locked position and the wedges are fully engaged into the mounting holes of the attachment (if applicable).
• Check that the implement is securely fastened to the machine.
• Depress brake pedals (or make sure parking brake is engaged) and make sure all the machine controls are in the NEUTRAL position before starting the machine. • Always start the machine from the operator’s seat.
• Operate the attachment / implement according to the Operation & Maintenance Manual.
• When learning to operate the attachment / implement, do it at a slow rate in an area clear of bystanders.
• DO NOT permit personnel to be in the work area when operating the machine and attachment / implement.
• The attachment / implement must be used ONLY on approved machines. See your Bobcat dealer for updated list of approved attachments / implements for each machine model.
• DO NOT modify equipment or add attachments / implements that exceed manufacturer’s specifications.
• DO NOT make any adjustments or repairs on the machine or attachment / implement while the engine is running.
• Keep shields and guards in place. Replace if damaged.
