BT Prime-Mover SN-20 SN-20R SN-30 SB-30R Electric Walkie Stacker Truck Operating & Part Manual PDF

Description

BT Prime-Mover SN-20 SN-20R SN-30 SB-30R Electric Walkie Stacker Truck Operating Maintenance & Part Manual – PDF DOWNLOAD

FILE DETAILS:

BT Prime-Mover SN-20 SN-20R SN-30 SB-30R Electric Walkie Stacker Truck Operating Maintenance & Part Manual – PDF DOWNLOAD

Language : English
Pages : 145
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:

TABLE OF CONTENTS:

BT Prime-Mover SN-20 SN-20R SN-30 SB-30R Electric Walkie Stacker Truck Operating Maintenance & Part Manual – PDF DOWNLOAD

301184-000 1969_September
301044-000 1974_April
301044-001 Before April_1980

Front Cover 2
Prime-Mover Warranty 3
To New Prime-Mover Owners 4
Contents 4
Operating Instructions 5
Preliminary Service 5
Controls 5
Safety Interlock 5
Lift-Lower 5
Direction Control 5
Deadman Brake 5
Key Switch (optional) 5
Horn 5
Dynamic Brake (optional) 5
Field Weakening (optional over-speed) 5
Time Delay 5
Operator Inspection and Maintenance Procedures 6
Daily 6
Weekly 6
Semi-Annually (or as required) 6
Battery Care 6
Maintenance Instructions 6
Battery 7
Power Wiring 7
Control Wiring 7
Control Switches (handle) 7
Mechanical Brake 7
Interlock Switch 8
Transmission Rollers 8
Contactor Points 8
Motor Commutator 8
Hydraulic System 8
Service and Disassembly Instructions 8
Handle 9
Direction Control Switches 9
Transmission 9
Drive Motor 9
Drive Gear Adjustment 9
Electric Control Panel 9
Hydraulic Pump 9
Lift Frame 9
Inner Column 9
Hydraulic Lift Cylinder 9
Gear Case Guide Ring 10
Parts Ordering Instructions 10
Parts List Index 11
Frame 12
Drive Wheel 12
Load Wheels 12
Shielding 12
Mast 14
Pin Type Forks and Lift Frame 14
Hook Type Forks and Lift Frame 14
Sheave Head 15
Frame Fittings 16
Control Handle 18
Transmission Assembly 12V 22
Drive Motor Service Parts 22
Transmission Assembly 24V 24
Drive Motor Service Parts 24
Electrical Control Panel 25
Power Wiring 27
Control Wiring 29
High Speed Rider 30
Schematic, Electrical 31
Hydraulic System (12V) 32
Hydraulic System (24V) 33
Hydraulic Pump and Motor (12V) 34
Hydraulic Pump and Motor (24V) 35
Hydraulic Valve 36
Hydraulic Cylinder 37
Service Guide 39
Back Cover 41
Manual Update Memo 42
Front Cover 44
Warranty 45
To New Owerners 46
Specifications 46
Operating Rules and Instructions 47
Periodic Maintenance Chart 51
Lubrication Chart 52
Maintenance Instructions 53
Service and Disassembly Instruction 56
Parts Ordering Instructions 59
Parts List and Service Reference Index 61
Shielding 63
Frame Assembly 65
22:1 Spur Gear Transmission 67
D-20513 12 Volt Drive Motor Assembly 69
D-20843 24 Volt Drive Motor Assembly 70
Control Handle Assembly 71
Electrical Schematic 73
Control Wiring 74
12 Volt Power Wiring Assembly 75
24 Volt Power Wiring Assembly 76
Electrical Control Panel 77
Square “D” Forward/Reverse and Speed Contactors 78
G E Forward/Reverse Contactor 79
G E 2ND Speed Contactor 81
Dynamic Brake 83
Control Switch Assembly 84
SN-20/30 & SN-20 24 Volt Hydraulic Piping Diagram 85
SN-30/40 24 Volt Hydraulic Piping Diagram 86
Reservoir Assembly 87
Manual Valve Wiring Diagram 88
Manual Control Valve Mounting/Piping 89
Valve Assembly 91
Manual Control Valve 92
Hydraulic Pump P-25428 93
Hydraulic Pump for P-25428 94
Motor for P-25428 95
Hydraulic Pump and Motor D-21421 & D-21422 97
Hydraulic Pump Motor for D-21421 $ D-21422 98
Lift Cylinder for White 3 Stage 99
White Masts – Three Stage 101
Lift Cylinder Assembly (Prime-Mover) 103
Prime-Mover Mast – 2 Stage 105
Gleason Hose Reel Assembly 107
Gleason Reel 35 Series 108
Reach Attachment 109
Service Guide 111
Back Cover 113
Front Cover 114
Prime-Mover Warranty 115
Contents 116
To New Prime-Mover Owners 116
Operating Instructions 117
Preliminary Service 117
Safety Interlock 117
Lift-Lower 117
Direction Control 117
Deadman Brake 117
Key Switch (Optional) 117
Horn (Optional) 118
Dynamic Brake (Optional) 118
Operator Maintenance 118
Daily 118
Weekly 118
Semi-Annually (or as required) 118
Battery Care 118
Maintenance Instructions 119
Battery 119
Power Wiring 119
Control Wiring 120
Control Switches (Handle) 120
Mechanical Brake 120
Interlock Switch 121
Transmission Rollers 121
Contactor Points 122
Motor Commutator 122
Hydraulic System 122
Service Instructions 123
Handle 123
Transmission 123
Drive Motor 123
Control Panel 123
Hydraulic Pump 123
Lift Frame 123
Inner Column 123
Hydraulic Cylinder 123
Gear Case Ring 124
Gear Backlash 124
Parts Ordering Instructions 124
How to Order a Part 124
How Parts Orders will be Handled 124
Instructions for Returning Parts 124
Parts List Index 125
Lift Assembly and Load Wheels 126
Transmission Assembly 128
Drive Motor and Transmission Mounting 129
Motor Service Parts 129
Shielding 130
Electrical Control Panel 131
Power Wiring 132
Control Handle 133
Control Wiring 134
Hydraulic Cylinder Assembly 135
Hydraulic Piping Diagram 135
Hydraulic Pump Parts List 136
Brake Linkage and Interlock Switch 137
Control Switch Installation 138
High Speed Rider 139
Dynamic Brake (Optional) 140
Horn (Optional) 141
Wiring Diagram, Hour Meter and Key Switch (Optional) 142
Service Guide 143
Back Cover 145

DESCRIPTION:

BT Prime-Mover SN-20 SN-20R SN-30 SB-30R Electric Walkie Stacker Truck Operating Maintenance & Part Manual – PDF DOWNLOAD

301184-000 1969_September
301044-000 1974_April
301044-001 Before April_1980

The Prime-Mover you have just purchased was carefully designed and manufactured to give you the greatest possible service. Your continued satisfaction with this machine is of interest to us and to the dealer from whom you purchased it.

• This manual contains information which is essential to satisfactory results from your investment. Acquaint yourself thoroughly with the information contained in this manual and assure that the operators, maintenance men and mechanics are also familiar with its contents. Good design, mat1~rials and workmanship have gone into this Prime-Mover machine; however, careful operation and adequate maintenance are equally important. Maintenance cannot be built in – moving parts need lubrication, fasteners need tightening, batteries need charging, and an “ounce of prevention” in the form of preventative maintenance will pay big dividends.
• Cooperating with us in helping you to keep your Prime-Mover operating at peak performance is an organization of distributors and dealers who have been selected because of their experience and reliability. Consult the one nearest you when you need parts or service and let him give you some additional information on how to get the most satisfactory service from your Prime-Mover.

S.V 30/01/2025
