Case 23 Mini Excavator Service Manual 7-23771 – PDF DOWNLOAD

Description

Case 23 Mini Excavator Service Manual 7-23771 – PDF DOWNLOAD

DESCRIPTION:

Case 23 Mini Excavator Service Manual 7-23771 – PDF DOWNLOAD

SAFETY
Follow the safety instructions given in this section and throughout this manual to prevent any risk of accident.
Parking the machine :

When parking the machine, proceed as follows:

Maintenance and adjustments.

• Do not carry out any maintenance operations until you have read and assimilated the instructions and warnings contained in this manual.
• Wear suitable clothing when servicing the machine. Avoid loose-fitting clothes. · When servicing the machine, place a “Do not start up” label on the instrument panel.
• Always wear eye protection when using a tool which can cause metal particles to be projected. Use a soft-faced hammer (copper or brass) when installing pins.
• Incorrectly performed maintenance or adjustments can cause serious injuries. If you do not understand a maintenance or adjustment procedure, consult your Dealer.
• If the attachment is raised or if the machine moves when there is no operator, serious injury can result. Before carrying out any servicing operations on this machine, proceed as follows:

1. Park the machine on flat, level ground.
2. Lower the attachment until it is resting on the
ground.
3. Shut down the engine and remove the starter
switch key.
4. Block the tracks to prevent any machine movement.

• To operate the machine or the attachment controls, it is essential for the operator to be seated in his seat. Any other manner of operation could cause a serious accident.
• This is a machine for one person only. No passenger is permitted.

TABLE OF CONTENTS:

Case 23 Mini Excavator Service Manual 7-23771 – PDF DOWNLOAD

1 GENERAL INFORMATION
Safety instructions, General Information and Torque Specifications ……………1001 7-23440GB
General Specifications………………………………………………………………………….1002 7-23450GB
2 ENGINE
Engine Removal and Installation ……………………………………………………………2000 7-23460GB
Radiator and Oil Cooler ………………………………………………………………………..2003 7-23470GB
Engine Basic Data, Engine Specifications, Special Torque
Specifications and Troubleshooting…………………………………………………….2401 7-23660GB
Cylinder Head and Valve Assembly………………………………………………………..2415 7-23670GB
Cylinder Block, Crankshaft, Pistons, Connecting Rods, Liners,
Timing Gear Housing and Flywheel…………………………………………………….2425 7-23680GB
Engine Lubrication System, Oil Pump and Relief Valve …………………………….2445 7-23690GB
Engine Cooling System, Thermostat, Water Pump, Fan ……………………………2455 7-23700GB
Filtration/Exhaust ………………………………………………………………………………..2465 7-23710GB
3 FUEL SYSTEM
Fuel System, Injection Pump, Injectors, Fuel Filter, Fuel Pump ………………….3412 7-23720GB
4 ELECTRICAL SYSTEM
Electrical Schematic……………………………………………………………………………..4001 7-23480GB
Starter Motor ……………………………………………………………………………………….4004 7-23730GB
Generator …………………………………………………………………………………………..4007 7-23740GB
5 UNDERCARRIAGE
Track Group………………………………………………………………………………………..5002 7-23490GB
6 DRIVE TRAIN
Travel Motor/Reduction Gear Assembly………………………………………………….6002 7-23500GB
Swing Reduction Gear ………………………………………………………………………….6003 7-23510GB
7 UNDERCARRIAGE HYDRAULICS
Hydraulic Swivel…………………………………………………………………………………..7004 7-23720GB
8 HYDRAULIC SYSTEM
Hydraulic Schematic, Inspections, Adjustments and Troubleshooting …………8001 7-23530GB
Swing Control Valve Dozer Blade ………………………………………………………….8005 7-23540GB
Hydraulic and Fuel Reservoir…………………………………………………………………8010 7-23560GB
Hydraulic High Pressure and Swing Pump………………………………………………8020 7-23570GB
Hydraulic Servo-Pump………………………………………………………………………….8021 7-23580GB
Swing Motor ………………………………………………………………………………………..8040 7-23590GB
Attachment / Swing Pilot Valves …………………………………………………………….8050 7-23600GB
Attachment Cylinders……………………………………………………………………………8080 7-23610GB
9 UPPERSTRUCTURE/ATTACHMENTS
Pedals and Levers ……………………………………………………………………………….9001 7-23620GB
Upperstructure and Turntable………………………………………………………………..9002 7-23630GB
Cab ……………………………………………………………………………………………………9007 7-23640GB
Bucket, Boom, Dipper, Pivot and Dozer Blade …………………………………………9008
