TO CASE SIDE SHIFT BACKHOE OWNERS:

This manual is to be used in conjunction with your basic vehicle manual, The care given your Case Backhoe will greatly influence the satisfaction and service life obtained.

• By using this manual as a guide, you will be assured of maximum service from your Case Backhoe. As an Authorized Case Dealer, we stock Genuine Case Parts, manufactured with the same skill and precision as the original.
• Our factory trained staff is kept well informed of the best methods for servicing Case Equipment and is ready and able to be of service to you.

INTRODUCTION :
Figure 1- Rear View of Backhoe – Loader
This Baokhoo is a versatile unit designed to do the toughest
digging jobs. Here are some outstanding features:
EASY SIDE-SHIFTING! The operator can shift the Backhoe from
side-to-side without leaving the operator’s seat. This off-center
feature permits full 90° swing while digging alongside buildings
and walls.
HYDRAULIC LOCKS: The sliding frame is held in position on
the main frame by four hydraulic looks. These locks are applied
and released by a valve on the control tower.
STABILIZERS: Rugged, rectangular tubular stabilize_rs, with extendible
legs, provide exceptional balance and stability while
digging. Each stabilizer has a flat pad for the base foot. Cleated
pads (standard equipment) can be easily bolted on or removed
as required. Rubber pads are available for hard surface operation.
