Case 35 BACKHOE FOR 450 450B 850 850B & W14 Parts Catalog Manual B1359 – PDF DOWNLOAD

Description

Case 35 BACKHOE FOR 450 450B 850 850B & W14 Parts Catalog Manual B1359 – PDF DOWNLOAD

DESCRIPTION:

Case 35 BACKHOE FOR 450 450B 850 850B & W14 Parts Catalog Manual B1359 – PDF DOWNLOAD

Indexes
Th.is parts catalog is arranged for easy identification of parts. Toe Alphabetical Index at the front of the catalog gives location of major groups and assemblies. Toe Numerical Index at the rear of the the catalog gives part numbers and the page on which they are listed.
Abbreviations and Terms
HHCS – Hex head capscrew.
NSS- Not sold separately.
REF – Reference. Used to clarify drawing.
RESERVED – No item listed.
UAR – Use as required.
Changes
When changes are made to the machine, revised pages for this catalog will be issued. These pages must be inserted into your catalog as soon as they are received. Failure to keep your catalog up to date will result in
confusion and may cause you to order wrong parts.
Orders :

Orders should specify correct part number,
fui! description, quantity required, machine
and engine model, machine and engine
serial numbers, method of shipment and
shipping address.
Right-Hand and Left-Hand Sides:

Toe terms right-hand and left-hand (abbreviated to L. H. and R. H. ) as used in this catalog indicate th.e right and left sides of th.e machine as viewed from the operator’ s seat for proper operation of th.e machine or attachment.

TABLE OF CONTENTS:

Case 35 BACKHOE FOR 450 450B 850 850B & W14 Parts Catalog Manual B1359 – PDF DOWNLOAD

B L
Boom …………………..•…………… 87 Light – rear …………..•…….•…………. 7
Buckets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97-103
Console – controls …………………….. 105
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109,111
Couplings – hydraulic …………………… 43
Cylinders – hydraulic
Boom ……………………………. 57,59
Bucket …………………………… 65,67
Dipper …………………………… 61,63
Dipper Extension …………………… 69,71
Stabilizer …………………………. 45,47
Swing ……………………………. 49-55
D
Decais ………………………………. 113
Dipper ……………………………….. 87
E
Extendable Dipper …………………… 93,95
F
Frame ………………………………… 83
Frost Tooth …………………………… 91
H
Hose and Fitting Conversion Part Numbers … 114
Hydraulic Circuits
Boom ……………………………. 17,19
Bucket …………………………… 23,25
Dipper ……………………………… 21
Dipper Extension …………………….. 27
Stabilizer …………………………. 11,13
Swing ………………………………. 15
Tractor to Backhoe ………. , ……….. 9-13
Printed in U.S.A.
Mounting Frame …………….•…..•…… 83
Mounting Parts – to tractor ……•……… 77-81
N
Numerical lndex ………………………. 115
s
Seat – operator’s …………………….. 73, 75
Stabilizers …………………………….. 83
SMV Emblem …………………………. 113
Swivel Fittings …………………………. 41
T
Teeth – buckets …………………….. 97-103
Tower – control ……………………. 105,107
Tower – swing …………………………. 87
V
Valve – backhoe control ………………. 31-39
Valve – stabilizer control …………………. 29
Valve Section – boom …………………… 39
Valve Section – bucket ………………….. 33
Valve Section – dipper …………………… 33
Valve Section – dipper extension ………….. 35
Valve Section – inlet …………………….. 31
Valve Section – outlet …………………… 31
Valve Section – swing …………………… 37
