Case 530 Construction King Forklift Operators Manual 9-70892 – PDF DOWNLOAD

Description

Case 530 Construction King Forklift Operators Manual 9-70892 – PDF DOWNLOAD

DESCRIPTION:

Case 530 Construction King Forklift Operators Manual 9-70892 – PDF DOWNLOAD

INTRODUCTION:

The 530 Construction King Fork Lift is ruggedly built for
continuous day in and day out work, with a minimum of maintenance.
Some of the outstanding features of the Fork Lift are:
1. HIGH TORQUE GASOLINE OR DIESEL ENGINES. High torque,
159 cubic inch Gasoline or 188 cubic inch Diesel, Case-built
engines that have been thoroughly proven through years of
field use are available in this Fork Lift.
2. DUAL-RANGE, SHUTTLE TRANSMISSION. A four speed transmission
used in conjunction with a high-low range box and
shuttle transmission provides the operator with a total of
eight speeds forward and eight speeds reverse. This enables
the operator to shift instantly from forward to reverse {and
vice versa) in the same transmission gear.
3. EASY STEERING AND MANEUVERING. Hydrostatic steering
with no mechanical linkage between the steering wheel and
front axle makes Fork Lift handling practically effortless.
The heavy duty, band actuated, disk brakes are fully enclosed
and operate on differential side gears for added leverage and
service accessibility.
4. CONVENIENTLY LOCATED CONTROLS AND INSTRUMENTS.
Instruments and operating controls are conveniently located
on the control tower in front of the operator for ease of
operation.
5. STANDARD OR HEAVY DUTY MASTS. Three sizes of standard
masts and two sizes of heavy duty masts are available
for the Fork Lift. Standard masts handle palletized materials,
boxes, building materials, etc. with ease. Heavy duty masts
are recommended when handling wide loads such as logs,
lumber, beams and similar loads.

TABLE OF CONTENTS:

Case 530 Construction King Forklift Operators Manual 9-70892 – PDF DOWNLOAD

• Introduction
• Serial Number Location
• General Specifications
• Lubrication
• Hydraulic System
• Operating Instructions
• Attachments
• Preventive Maintenance
• Table of Contents

IMAGES PREVIEW OF THE MANUAL:
