GENERAL INFORMATION
Indexes
This Parts (kudos is arranged for easy identification of Genuine CASE Service Parts. index is: provided at the front of this Catalog to [onto the major gram or assemblies. A numerical index at the rear of the Catalog gives the part numbers and the pages on which they are described.
Illustrations
‘ All’ parts are illustrated in “Exploded Views” which show the individual parts in their normal relationship to each other. Reference numbers are used in the illustrations. These numbers correspond to those in the “Reference Number” column and are followed by the part number, description and quantity required.
Orders ‘
Orders should plainly Specify correct part number, full description, quantity required, machine model and engine model, machine and engine serial numbers, method of shipment and shipping address.
Changes
When changes to the machine make it necessary, revised pages for this book will be issued. The revised pages will be issued with the same page number as those they replace and the “issue” number and date will be advanced. It is imperative that revised Parts Book pages be inserted into their respective Parts Books as soon as received. Failure to do so will lead to confusion and defeat the purpose of the book
Indented Description
Indented parts in the description list are a part of the preceding assembly or sub-assembly. The quantity shown in the “Number Required” column is the number of parts used on a ma- chine except where parts are indented in descriptive list. In this case the quantity shown ‘is the number required for the preceding assembly or sub-assembly.
Terms “Right Hand” and “Left Hand” . “Front“ and “Rear”
The terms “Right Hand” and “Left Hand” The terms “Front” and “Rear” of the sides of the fork lift are determined by sitting ‘ fork lift are also determined by sitting in in the operator’s seat facing the mast. the operator’s seat facing the mast
TABLE OF CONTENTS:
CASE 580 Forklift Construction King Parts Manual – PDF DOWNLOAD
2 MODEL 580 CONSTRUCTION KING FORK LIFT
ALPHABETICAL INDEX
A H
Accessory Attachments – Optional . . . . . . 17-27
Accessory Hydraulics – Loader Bucket
(10-1/2′, 12′ and 14-1/4′ Masts) . . 45
Accessory Hydraulics – Loader Bucket
(21-1/2′ Mast) . . . . . . . . . . . 47
Accessory Hydraulics – Log Clamp . . . . . 23
Accessory Hydraulics – Side Shifter
(4000 lb. lift capacity) . . . . . . . . . . 17
Accessory Hydraulics – Side Shifter
(5000 lb. lift capacity) . . . . . . . . . . 19
B
Hose and Fitting Conversion Part
Numbers . . . . . . . . . . . . . . . . . . . . . . 65
Hydraulics – Fork Lift Primary . . . . . . . 41
Hydraulics – Lift Cylinder . . . . . . . . . . . . . . 43
Hydraulics – Loader Bucket
(10-1/2′, 12′ and 14-1/4′ Masts) . . . . . . . . 45
Hydraulics – Loader Bucket (21-1/2′ Mast). . . 47
Hydraulics – Log Clamp . . . . . . . . . . . . . 23
Hydraulics – Side Shifter
( 4000 lb. Lift Capacity) . . . . . . . . . . . 17
Hydraulics – Side Shifter
(5000 lb. Lift Capacity) . . . . . . . . . . . . 19
Hydraulics – Steering . . . . . . . . . . 35
Hydraulics – Tilt Cylinder . . . . . . . . . . . . 43
Blade – Dozer
Boom – Crane … .
Bucket – Loader … .
Bucket – Cement
Brake – Pedals and Linkage
25 Lamps – Head . . . . . .• . . . . . . . . . . . . . . 37-39
31 Levers – Fork Lift Control . . . . . . . . . . . . . . 33
Linkage – Brakes . . . . . . . . . . . . . . . . . . . . 31
Linkage – Clutch . . . . . . . . . . . . . . . . . . . . 31
Linkage – Foot Throttle . . . . . . . . . . . . . . . 31
Linkage – Shuttle . . . . . . . . . . . . . . . . . . . . 33
Chun Lift .• . . . . . . . . . . . . . . . 7-15, 19
| Clutch – Pedal and Linkage . . . . . . . . . . . . . . | 31 |
| Control Tower . . . . . . . . . . . . . . . . • . . . • . | 29 |
| Control – Levers and Linkage . . . . . . . . . . . . | 33 |
| Counterweight – Fork Lift . . . . . . . . . . . . . . | 5 |
| Counterweight – Hydraulic Hose . . . . . . . . . . . | 47 |
| Cylinder – Lift (10-1/2′ Mast) • . . . . . . . . . . . | 49 |
| Cylinder – Lift (12′ Mast) . .• . .• • . . . . . . . . | 49 |
| Cylinder – Lift (14-1/4′ Mast) . . . . . . . . . . . . | 51 |
| Cylinder – Lift (21-1/2′ Mast) . . . . . . . . . . . . | 51 |
| Cylinder – Loader Bucket . . . . . . . . . • . . . . . | 53 |
| Cylinder – Log Clamp . .• . . . . . . . . . • . . . | 59 |
Cylinder – Side Shift . . . . . . . .• . . . . . . . 53, 57
Cylinder – Tilt ………….• ,….. 53,55
M
Mast and Related Parts
(10-1/2′ 4000 lb. Lift Capacity). . . . . . . . . . 7
Mast and Related Parts
(12′ 5000 lb. Lift Capacity) . . . . . . . . . . . 13
Mast and Related Parts
(14-1/4′ 4000 lb. Lift Capacity) . . . . . . . . . 9
Mast and Related Parts
(14-1/4′ 5000 lb. Lift Capacity) . . . . . . . . 15
Mast and Related Parts
(21-1/2′ 4000 lb. Lift Capacity) . . . . . .• . 11
D
Decal Kit
Numerical Index
Drive – Pump ……..•………….. 41
E
Electrical System – Diesel . . • .• . 37
Electrical System – Gasoline . . . . 39
f
Filter – Hydraulic Oil . . . . . . . . . . . . . • . 41
Forks – Cement Block . . . . . . . . . . . . . . . . . . 21
Forks – Logging. . . . . . . . . . . . . . . . . . . . . . 21
Forks – Pallet . . . . . . . . . . . . . . . . . . . . . . 21
Frame – Fork Lift Sub . . . . . . . . . . . . . . . . . . 5
Pedals – Foot 31
Pump – Drive .•…• 41
Pump – Hydraulic ….. . 61
s
Seat – Fork Lift, Operator’s . . . . . . . . .• . .• 35
Shuttle – Lever and Linkage . . . . . .• .• . .• . 33 Side Shifter – 4000 lb. Lift Capacity . . . . . . . . 17
Side Shifter – 5000 lb. Lift Capacity. . . . .• . . . 19
Steering – Wheel and Hydraulics . . . . . . 35
Subframe – Fork Lift . . . . . . . . . . . . . . . . . 5
T
Tanks – Fuel . . . . . . . . . . . . . . . . . . . . . . 5
Tool Box . . . . . . . . . . . . . . . . . • . . . . 5
Tower – Control 29
G V
Guard – Overhead
29 Valve – Hydraulic Control …..•……… 63
2 MODEL 580 CONSTRUCTION KING FORK LIFT
ALPHABETICAL INDEX
A H
Accessory Attachments – Optional . . . . . . 17-27
Accessory Hydraulics – Loader Bucket
(10-1/2′, 12′ and 14-1/4′ Masts) . . 45
Accessory Hydraulics – Loader Bucket
(21-1/2′ Mast) . . . . . . . . . . . 47
Accessory Hydraulics – Log Clamp . . . . . 23
Accessory Hydraulics – Side Shifter
(4000 lb. lift capacity) . . . . . . . . . . 17
Accessory Hydraulics – Side Shifter
(5000 lb. lift capacity) . . . . . . . . . . 19
B
Hose and Fitting Conversion Part
Numbers . . . . . . . . . . . . . . . . . . . . . . 65
Hydraulics – Fork Lift Primary . . . . . . . 41
Hydraulics – Lift Cylinder . . . . . . . . . . . . . . 43
Hydraulics – Loader Bucket
(10-1/2′, 12′ and 14-1/4′ Masts) . . . . . . . . 45
Hydraulics – Loader Bucket (21-1/2′ Mast). . . 47
Hydraulics – Log Clamp . . . . . . . . . . . . . 23
Hydraulics – Side Shifter
( 4000 lb. Lift Capacity) . . . . . . . . . . . 17
Hydraulics – Side Shifter
(5000 lb. Lift Capacity) . . . . . . . . . . . . 19
Hydraulics – Steering . . . . . . . . . . 35
Hydraulics – Tilt Cylinder . . . . . . . . . . . . 43
Blade – Dozer
Boom – Crane … .
Bucket – Loader … .
Bucket – Cement
Brake – Pedals and Linkage
25 Lamps – Head . . . . . .• . . . . . . . . . . . . . . 37-39
31 Levers – Fork Lift Control . . . . . . . . . . . . . . 33
Linkage – Brakes . . . . . . . . . . . . . . . . . . . . 31
Linkage – Clutch . . . . . . . . . . . . . . . . . . . . 31
Linkage – Foot Throttle . . . . . . . . . . . . . . . 31
Linkage – Shuttle . . . . . . . . . . . . . . . . . . . . 33
Chun Lift .• . . . . . . . . . . . . . . . 7-15, 19
| Clutch – Pedal and Linkage . . . . . . . . . . . . . . | 31 |
| Control Tower . . . . . . . . . . . . . . . . • . . . • . | 29 |
| Control – Levers and Linkage . . . . . . . . . . . . | 33 |
| Counterweight – Fork Lift . . . . . . . . . . . . . . | 5 |
| Counterweight – Hydraulic Hose . . . . . . . . . . . | 47 |
| Cylinder – Lift (10-1/2′ Mast) • . . . . . . . . . . . | 49 |
| Cylinder – Lift (12′ Mast) . .• . .• • . . . . . . . . | 49 |
| Cylinder – Lift (14-1/4′ Mast) . . . . . . . . . . . . | 51 |
| Cylinder – Lift (21-1/2′ Mast) . . . . . . . . . . . . | 51 |
| Cylinder – Loader Bucket . . . . . . . . . • . . . . . | 53 |
| Cylinder – Log Clamp . .• . . . . . . . . . • . . . | 59 |
Cylinder – Side Shift . . . . . . . .• . . . . . . . 53, 57
Cylinder – Tilt ………….• ,….. 53,55
M
Mast and Related Parts
(10-1/2′ 4000 lb. Lift Capacity). . . . . . . . . . 7
Mast and Related Parts
(12′ 5000 lb. Lift Capacity) . . . . . . . . . . . 13
Mast and Related Parts
(14-1/4′ 4000 lb. Lift Capacity) . . . . . . . . . 9
Mast and Related Parts
(14-1/4′ 5000 lb. Lift Capacity) . . . . . . . . 15
Mast and Related Parts
(21-1/2′ 4000 lb. Lift Capacity) . . . . . .• . 11
Drive – Pump ……..•………….. 41
E
Electrical System – Diesel . . • .• . 37
Electrical System – Gasoline . . . . 39
f
Filter – Hydraulic Oil . . . . . . . . . . . . . • . 41
Forks – Cement Block . . . . . . . . . . . . . . . . . . 21
Forks – Logging. . . . . . . . . . . . . . . . . . . . . . 21
Forks – Pallet . . . . . . . . . . . . . . . . . . . . . . 21
Frame – Fork Lift Sub . . . . . . . . . . . . . . . . . . 5
Pedals – Foot 31
Pump – Drive .•…• 41
Pump – Hydraulic ….. . 61
s
Seat – Fork Lift, Operator’s . . . . . . . . .• . .• 35
Shuttle – Lever and Linkage . . . . . .• .• . .• . 33 Side Shifter – 4000 lb. Lift Capacity . . . . . . . . 17
Side Shifter – 5000 lb. Lift Capacity. . . . .• . . . 19
Steering – Wheel and Hydraulics . . . . . . 35
Subframe – Fork Lift . . . . . . . . . . . . . . . . . 5
T
Tanks – Fuel . . . . . . . . . . . . . . . . . . . . . . 5
Tool Box . . . . . . . . . . . . . . . . . • . . . . 5
Tower – Control 29
G V
Guard – Overhead
29 Valve – Hydraulic Control …..•……… 63
