Case CX210 Crawler Excavator Service Manual 7-29041 - PDF DOWNLOAD

Case CX210 Crawler Excavator Service Manual 7-29041 – PDF DOWNLOAD

Name: Case CX210 Crawler Excavator Service Manual 7-29041 - PDF DOWNLOAD
SKU: 291354
Availability: InStock

Original price was: $89.95.Current price is: $30.95.

Case CX210 Crawler Excavator Service Manual 7-29041 – PDF DOWNLOAD

Category: CASE Tags: Case CX210 Crawler Excavator Service, Case CX210 Crawler Excavator Service Manual 7-29041, Case CX210 Crawler Excavator Service Manual 7-29041 - PDF DOWNLOAD Vendor: Repair Time Manuals

⚡

Instant PDF Download

Available immediately

💾

Save to Your Device

Download & keep forever

🛡️

Antivirus Scanned

100% virus-free

🌍

Trusted Worldwide

175,000+ customers

Description

Description

Case CX210 Crawler Excavator Service Manual 7-29041 – PDF DOWNLOAD

DESCRIPTION:

Case CX210 Crawler Excavator Service Manual 7-29041 – PDF DOWNLOAD

Cleaning :

Clean all metal parts except bearings, in a suitable cleaning solvent or by steam cleaning. Do not use caustic soda for steam cleaning. After cleaning, dry and put oil on all parts. Clean oil passages with compressed air. Clean bearings in a suitable cleaning solvent, dry the bearings completely and put oil on the bearings.

Inspection:

Check all parts when the parts are disassembled. Replace all parts that have wear or damage. Small scoring or grooves can be removed with a hone or crocus cloth. Complete a visual inspection for indications of wear, pitting and the replacement of parts necessary to prevent early failures.

Bearings :

Check bearings for easy action. If bearings have a loose fit or rough action replace the bearing. Wash bearings with a suitable cleaning solvent and permit to air dry. DO NOT DRY BEARINGS WITH COMPRESSED AIR.

Needle :

Bearings Before you press needle bearings in a bore always remove any metal protrusions in the bore or edge of the bore. Before you press bearings into position put petroleum jelly on the inside and outside diameter of the bearings.

Gears :

Check all gears for wear and damage. Replace gears that have wear or damage.

Oil Seals, O-Rings and Gaskets :

Always install new oil seals, O-rings and gaskets. Put petroleum jelly on seals and O-rings.

Shafts :

Check all shafts that have wear or damage. Check the bearing and oil seal surfaces of the shafts for damage.

Service Parts :

Always install genuine Case service parts. When ordering refer to the Parts Catalog for the correct part number of the genuine Case replacement items. Failures due to the use of other than genuine Case replacement parts are not covered by warranty.

Lubrication:

Only use the oils and lubricants specified in the Operator’s or Service Manuals. Failures due to the use of non-specified oils and lubricants are not covered by warranty.

TABLE OF CONTENTS:

Case CX210 Crawler Excavator Service Manual 7-29041 – PDF DOWNLOAD

1 GENERAL INFORMATION
SECTION N°
Safety, general information and standard torque data ………………………………. 1001
General specifications and special torque setting …………………………………….. 1002
Numerical value conversion tаЫе ………………………………………………………….. 1003
2 ENGINE
Removal and installation of the engine …………………………………………………… 2000
Radiator and oil-cooler …………………………………………………………………………. 2001
Engine specifications ………………………………………………………………………………… *
DisassemЫy and assemЫy ofthe engine …………………………………………………….. *
З FUEL SYSTEM
Fuel tank ……………………………………………………………………………………………. 3001
Fuel engine system …………………………………………………………………………………… *
4 ELECTRICAL SYSTEM
Electrical system, electrical and electronic trouЫeshooting ………………………. .4001
lnspection and maintenance of batteries and connecting а booster battery … .4002
5 UNDERCARRIAGE
Removal and installation of tracks …………………………………………………………. 5001
Rollers ……………………………………………………………………………………………….. 5003
Sprocket …………………………………………………………………………………………….. 5004
ldler wheel and tension shock absorber …………………………………………………. 5005
6 DRIVE TRAIN
Drive motor and final drive transmission removal and installation ………………. 6001
Drive motor and final drive transmission disassemЫy and assemЫy ………….. 6002
Swing reduction gear, removal and installation ………………………………………… 6003
Swing reduction gear, disassemЫy and assemЫy ……………………………………. 6004
7 UNDERCARRIAGE HYDRAULICS
8 UPPERSTRUCTURE HYDRAULICS
Depressurising and decontaminating the hydraulic system, use of the
vacuum pump and Ыeeding the components ………………………………………. 8000
Specifications, trouЫeshooting, checks and hydraulic pressure settings ……… 8001
Hydraulic reservoir removal and installation ……………………………………………. 8002
Main and pilot pumps, removal and installation ……………………………………….. 8003
Main hydraulic control valve, removal and installation ………………………………. 8004
Attachment cylinders, removal and installation ………………………………………… 8005
Hydraulic swivel, removal and installation ……………………………………………….. 8006
Pilot Ыосs, removal and installation ……………………………………………………….. 8007
Swing motor, removal and installation …………………………………………………….. 8008
DisassemЫy and assemЫy ofthe free swing valve ………………………………….. 8009
Main hydraulic pump, disassemЫy and assemЫy ……………………………………. 801 О
Main hydraulic control valve, disassemЫy and assemЫy ………………………….. 8011
Attachment cylinders, disassemЫy and assemЫy ……………………………………. 8012
Hand control levers, disassemЫy and assemЫy ……………………………………… 8013
Foot control levers, disassemЫy and assemЫy ……………………………………….. 8014
Six-solenoid valves, disassemЫy and assemЫy ………………………………………. 8015
Caution valve, disassemЫy and assemЫy ………………………………………………. 8016
Safety valve ………………………………………………………………………………………… 8017
Hydraulic swivel, disassemЫy and assemЫy …………………………………………… 8018
Swing motor, disassemЫy and assemЫy ……………………………………………….. 8019
Hydraulic functions ………………………………………………………………………………. 8020
9 UPPERSTRUCTURE
Upperstructure, turntaЫe and counterweight …………………………………………… 9002
Boom, dipper and bucket ……………………………………………………………………… 9003
Seat and seat belt ……………………………………………………………………………….. 9004
СаЬ and саЬ equipment ……………………………………………………………………….. 9005
Air conditioner trouЫeshooting and system checks ………………………………….. 9006
Air conditioning unit disassemЫy and assemЫy ………………………………………. 9007
Air conditioning servicing ……………………………………………………………………… 9008
Air conditioning components …………………………………………………………………. 9009
Large format hydraulic and electrical schematics ………………………………….. Pocket
