Case W20B Articulated Loader Operators Manual 9-6002 – PDF DOWNLOAD
Original price was: $89.95.$25.95Current price is: $25.95.
Case W20B Articulated Loader Operators Manual 9-6002 – PDF DOWNLOAD
Description
Case W20B Articulated Loader Operators Manual 9-6002 – PDF DOWNLOAD
IMAGES PREVIEW OF THE MANUAL:
DESCRIPTION:
Case W20B Articulated Loader Operators Manual 9-6002 – PDF DOWNLOAD
TO THE OWNER :
This manual is your guide to safe, efficient operation. Before you operate
this machine, read this manual.
When you get your new machine from your J I Case dealer, you will be told
about correct operation and maintanance as shown in the Owner Warranty
Registration form. When your J-·1 Case dealer has given you these instructions,
you must write your name on the report. Then your dealer will give you a copy
for your records.
AFTER DELIVERY CHECK:
One copy is for you, one copy is for the dealer and one copy is for the
Construction Equipment Service Department. Make sure that your J I Case
dealer does the After Delivery Check after the first 20 hours of machine
operation.
TABLE OF CONTENTS:
Case W20B Articulated Loader Operators Manual 9-6002 – PDF DOWNLOAD
Introduction 2
Safety 4
Spark Arresting System 17
Roll-Over Protective Structure 18
Location of PIN Number and
Serial Numbers 22
Specifications 23
Operating Instructions 28
Instruments and Controls 28
Loader Controls 40
Engine Operation 45
Walk-Around Checks Before
Starting 46
Starting the Engine 47, 48
Stopping the Engine 49
Machine Operation 53
Transmission Controls 53
Auxiliary Steering 54
Stopping 55
Towing 55
Transporting the Machine 56
Cold Weather Operation 59
Hot Weather Operation 60
Loader Operation 61
Loading and Dumping
the Bucket 62
Return-To-Dig , 63
Bucket Height Control 64
Clutch Cutout 64
Fuels and Lubricants 66
Diesel Fuel 66
Fuel, Fluids and
Lubricants Chart 67
Maintenance/Lubrication 68
Introduction 68
Run-In Maintenance Chart 69
Scheduled Maintenance Chart 69
Safety Before You Do Service 72
Transport/Service Link 73
Grease Fittings 74
Engine Lubrication System 76
Engine Air Cleaning System 79
Engine Cooling System 84
Drive Belts 86
Fuel System 89
Electrical System 95
Equipment and Steering
Hydraulic System 104
Braking System 106
Transmission Hydraulic
System 109
Axles 112
Wheels and Tires 114
Loader Service 116
Return-To-Dig Adjustment 116
Bucket Height Control
Adjustment 116
Bucket Teeth 118
Cold Start Aid 119
ROPS Cab and Air
Conditioner 120
Seat Belts 123
Machine Storage 128
Removal From Storage 129
Spark Arrester Muffler 131
After Delivery Check 133
