DESCRIPTION:

Case W24B Articulated Loader Parts Catalog Manual C1216 – PDF DOWNLOAD

Indexes:
This parts catalog is arranged for easy identification on parts. The Alphabetical Index at the front of the catalog gives location of major groups and assemblies. The Numerical Index at the rear of the catalog gives part numbers and the page on which they are listed.
Abbreviations and Terms:
PIN – Product Identification Number.
SN – Serial Number.
NSS – Not sold separately.
REF – Reference. Used to clarify drawing.
RESERVED – No item listed.
UAR – Use as required.
Changes:
When changes are made to the machine, revised pages for this catalog will be issued. These pages must be inserted into your catalog as soon as they are received. Failure to keep your catalog up to date will result in confusion and may cause you to order wrong parts.
Orders :
Orders should specify correct part number, full description, quantity required, machine and engine model, machine and engine serial numbers, method of shipment and shipping address.

TABLE OF CONTENTS:

Case W24B Articulated Loader Parts Catalog Manual C1216 – PDF DOWNLOAD

A
Air Cleaner · 59
Alternator 35,35B
Mounting And Adjusting Strap 9,33;35D,43,47
Axle Assembly, front
Pinion Bearings And Companion Flange 99
Pinion, Ring Gear And Differential Case 101,101B
Planetary 103,103B
Axle Assembly, rear ·
Pinion Bearings And Companion Flange 105
Pinion, Ring Gear And Differential Case 107,107B
Planetary 109,109B
Axle Mounting – 101,101B,107,107B
B
Backup Alarm 89B
~··· · ···· ···········49,49K
Cab s · 49,49K
Beacon, rotating 183,185
Belts
Alternator 43
Compressor 43
Seat 171
Block, engine cylinder 19-19D
Block Heater 19-19D
Brake Assemblies And Circuits _
Air Compressors And Related Parts
117 ,117B,121,123,123B,123D
Air Pressure Protection Valve 129,139
Alcohol Evaporator 119
Axle Brake 103,109,111
Brake Valve 127,135
Emergency Brake To Safety Chamber 115
Governors, air compressor 125
Master Cylinder 137
,Master Cylinder To Wheel Cylinders 133
Parking Brake, transmission 77, 77B
Treadle Assembly 135
Treadle To Front Master Cylinder
And Reservoir 129,131
Treadle To Rear Master Cylinder
And Reservoir 127
Buckets
Standard 189
Teeth 189,189B,191
4-in-1 Bucket 191
C
Cab, operator’s 175,l 77,l 77B-l 77H
Camshaft, engine 17B
Clutch, transmission 71,73,71′
Cold Starting System (Ether injection) 51,51B,51D
Compartment, operator’s 171,173
Compressor, air ll 7,ll 7B,121; 125
Connecting Rods, engine 23
Control Levers
Clutch Cutout 143
Loader Height And Leveling 215
Loader Lift and Bucket 211,213
Pedal, accelerator 63
Pedal, ~rake (Treadle) 127,129,135
Transmission ·; 87 ,89
Counterweight 157
Crankshaft, engine 21,21B
Cushions, seat 171
740112 C
:c
Cylinders, brake –
Master 133,137
Slave 111
Cylinders, hydraulic
· Bucket Clam 207 ,207B
Bucket Tilt 205,205B
– Loader Lift · 203-203D
Steering : 11>5,165B
D
Decals
Bucket (4-in-1) 191
Engine Data 15
Kit 229-231
Defroster, cab 179
Dipsticks · ·
Engine Oil · : 19
Hydraulic Tank 167
Transmission Oil · · , 85
Drive Shaft
Center Bearing 93
Front, axle end 95,95B
Front, transmission end 91,91B
Rear · 97,97B
E
Electrical Systems
Bucket Height· 215,215B
Cab Wiring · ; -~ : 175,179,181
Cold Starting Systems , 4 7 ,51
Harnesses ; 45-49K
Instrument Cluster 49F
Instrum:int Panels 55,57,49B,49D,55,57
Return-To-Dig 215,215D
Emblem, slow moving vehicle 229
Engine Mounts 43
Engine Subassemblies
Alternator 35,35B
Camshaft · 17
Crankshaft 21,21B
Cylinder Block : 19-19D
Cylinder Head And Cover 15
Flywheel And Housing 21-21D
Fuel Filter System 31
Fuel Injection System 29
Gasket Kits 27
Injection Nozzles 33B,33F
Injection Pump 33B,33D
Injection Pump Drive 33
Manifolds, intake and exhaust 13
Oil Filter And Heat Exchanger 11,llB
Oil Pum ‘l And Pan 25
Piston And Connecting Rods 23,23B
Starter 37-41
Timing Gear Cover ; 33
Turbocharger 13B,13D
Valve Mechanism 17
Water Manifold And Thermostat 9
Water Pump · 9B
Evaporator, alcohol – 119
Exhaust, pipe and mufflers 61
F
Fan, radiator 43
Mounting 9,43
Fenders 165,169
Filters
Air Cleaner 59
Air, governor 125
Engine Cil · · 11,llB
Fuel 31,33B,161,167
Hydraulic Tank ; 167
Transmission Oil · 67,83,85
Flasher Lights 175,175B
Floor Plates 171,173
Flywheel, engine 21-21D
Frames
ArticUlated, front 169;169B
Articulated, rear – 157
Loader Lift 187,187B
Fuel Injector 29,33B,33D
Fuel Lines 29,31,161
Fuel Tank 161
G
Gaskets, engine (Service Kits) 27
Gauges 55-59
Gears
Engine (See Engine Subassemblies)
Transmission (See Transmission Subassemblies)
Glass and Molding 177D,l 77H
Governors, air compressor 123,125
Grille 163
Guards
Engine Side Panels 165
Roll-Over Protection Structure 177
Undercarriage ; : 159
H
Head, engine 15
Heater
Block, engine · 19-19D
Cab 179,181
Manifold · 13,47
High Altitude Compensating Kit 13B
Hood 163
Horn, air 145
Hose And Fitti:’,g Chart 230
Hose, radiator 43
Hoses (See Fuel Lines, Brake Assemblies And
HydraUlic Circuits)
HydraUlic Circ· : its
Loader Bucket (Clam) 191,201,201B
Loader Bucket (Tilt) 199
Loader LL”t 197
Primary 193
Pump To Loader Valve · 195
Steering, pump to cylinders 153
Steering, pump to reservoir 151
Transmissioo 83
HydraUlic Tank Assemblies 167
Printed in U S A
740113 C
Index, numerical 231
Instrument Panel 55,57
Instruments (See Gauges)
L
Lights 53,175,183,185
Loader Arm; mechanical Parts 187,187B
M
Manifold
Exhaust 13
Heater 13,47
Intake 13
Water 9
Mounts
Axle 101,107
Engine 43
Radiator : 43
Transmission 85
Mufflers 61
N
Noise Reduction Parts 177K ·
Nozzle, fuel injector· 33B,33D
0
Oil Cooler, engine 11
Gil Pan, engine 2 5
p
Parking Brake 77,115
Pedal, accelerator · 63
Pedal, brake (Treadle) 127,129,135
Piston Assemblies, engine 23
Plates, floor 171,173
Pulleys
Air Compressor 117
Alternator 35,3513,43
Alternator And Fan Drive 21
Fan Mounting 9
Pump Drive, water 9
Pumps
Engine, oil 25
Fuel, electrical 161,167
Fuel Injection 33B
HydraUlic Oil 151,193,195,209,209B
Steering 147-147F
Torque Converter 65
Transm ission Charging 79
Water, engine _ ‘ 9B
Issued June, 1975
MOD&L W24B ARTICULATED LOADER
ALPHABETICAL INDEX
R
Radiator, cooling 43
Regulator, voltage 47
Reservoirs
Air · li7
Fuel 161
Hydraulic Oil · 167
Rims, wheel 113
Rings, engine piston 23,23B
Rocker Arms, engine 17
Rods, connecting 23,23B
Rods, push 17
Roll-Over Protection structure and Cab 177
s
Seat Assemblies ; 171,173
Shafts
Axle (See Axle Assemblies)
Engine (See Engine Subassemblies)
Transmission (See Transmission $ubassemblies}
Shroud, radiator ; : 163
Side Panels, engine 165
Side Panels, operator’s compartment 171
Sleeve, piston 23
Solenoid
Manifold Heater 47
Starter 41
Starter, engine 37-41,43,47
Starting Aid (Ether Injection) 51
Steps·169·
T
Thermostat, water temperature 9
Timing Gear And Cover, engine 33
Tire Inflation Kit 127
Tools, service 229
Torque Converter 65,65B
· Transmission Mounts 85
Transmission Subassemblies
Axle Output Shaft and Parking Brake 77, 77B
Charging Pump 79,79B
Control Valve 79, 79B
Converter Housing, Gears And
Transmission: Housing 67,67B
Forward Clutch And Planetary 71
Front Cover, Input Shaft And Torque
Converter · 65,65B
High Range Clutch And Transfer Gear 75
Overhaul Kit 81
Reverse Clutch And Planetary 73
Treadle Assembly 127,129,135
Turbine Driven Gears And Freewheel Unit 69
740114 B
T
Trunnion, rear frame · ; 157
Turbochargi,ng System 13B,13D
Turn Signals , 175;175B
V
Valve Mechanism, engine , 17
Valve Parts, loader control 221-227
Valves ·
Air Shutoff , 12-9
Air Pressure Protection 129,139
Air Pressure Regulator 141
· Brake Control 127 ,135
Breather, axle 101,107
Breather, transmission 67
Clutch Cutout 139,143
Emergency Brake 115
Drain, air reservoir · 129
Drain, engine block 19
Drain, engine oil cooler 11
Drain, radiator 43
Flow Control, steering 151
Horn 145
Loader Control, 2 spool 211,217
Loader Control/3 spool -· , ;213,219
Tire, valve stem · : 113
Torque Converter · · ~ 67 ·
Transmission Control , 79
w
Wheel, steering 147
Wheel, tire · 113
Windows and glass 177B-177H
Wiper, windshield 175
Wire (See Electrical Circuits)
