DESCRIPTION:

Case W4 Loader Forklift Parts Catalog Manual 8-1820 – PDF DOWNLOAD

Indexes:
This parts catalog is arranged for easy identification on parts. The Alphabetical Index at the front of the catalog gives location of major groups and assemblies. The Numerical Index at the rear of the catalog gives part numbers and the page on which they are listed.
Abbreviations and Terms:
PIN – Product Identification Number.
SN – Serial Number.
NSS – Not sold separately.
REF – Reference. Used to clarify drawing.
RESERVED – No item listed.
UAR – Use as required.
Changes:
When changes are made to the machine, revised pages for this catalog will be issued. These pages must be inserted into your catalog as soon as they are received. Failure to keep your catalog up to date will result in confusion and may cause you to order wrong parts.
Orders :
Orders should specify correct part number, full description, quantity required, machine and engine model, machine and engine serial numbers, method of shipment and shipping address.

TABLE OF CONTENTS:

Case W4 Loader Forklift Parts Catalog Manual 8-1820 – PDF DOWNLOAD

A
Air Cleaner and Restriction Indicator ….. 17-21
Alarm – backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Alternator – electrical ………………… 39,45
Alternator Mounting …………………. 45,47
Antirollback – loader bucket linkage …….. 171
Articulation Joint …………………….. 191
Auxiliary Hydraulics – loader ……….. 133,167
Axle Assembly …………………… 109,111
Axle Mounting
Front …………………………….. 101
Rear ………………………………. 99
B
Backup Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Battery ……………………………. 49,51
Battery Compartment . . . . . . . . . . . . . . . . . . . . . . 189
Belts
Fan and Alternator ………………… 45,47
Seat ……………………………… 197
Box – operators manual . . . . . . . . . . . . . . . . 193, 195
Brake System . . . . . . . . . . . . . . . . . . . . . 103, 115-119
Buckets – loader . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
Bucket Teeth – loader …………………. 173
C
Canopy – ROPS ……………………… 199
Carriage – forklift …………………. 181,183
Chain – forklift ………………………. 181
Chart – Hose Fitting and Conversion …….. 202
Chassis – tractor …………………. 187-191
Column – steering ………………… 59,63,65
Controls
Brake …………………………. 115,117
Directional – forward and reverse ……. 81-93
Engine Speed – throttle …………….. 35,37
Forklift . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Loader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165, 167
Steering …………………………… 59
Transmission …………………….. 95,97
Cooling Systems
Engine ………………………….. 13,15
Hydraulic …………………………. 123
Counterweights – rear ………………… 185
Cylinders – hydraulic
Bucket – loader …………………….. 159
Lift – forklift ……………………….. 161
Lift – loader ……………………….. 157
Steering …………………………… 67
Tilt – forklift ……………………….. 163
D
Decals ……………………………… 201
Differential . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109, 111
Dipstick – hydraulic reservoir …………… 189
Drive Shaft and Disc Brake …………….. 103
E
Electrical System and Components . 39-43,49-57
Engine and Engine Mounting …………. 25,27
Engine Oil Drain ……………………… 29
Exhaust System and Muffler . . . . . . . . . . . . . . . . 23
F
Fans – engine cooling ………………… 13, 15
Fenders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189
Filters
Air – engine ……………………… 17-21
Fuel – engine ……………………….. 33
Hydraulic oil ……………… 61,125,127,155
Flywheel Cover and Pump Mounting
Plate ……………………………. 69,71
Forks – loader ……………………….. 175
Forklift
Carriage ………………………. 181,183
Controls – hydraulic ………………… 177
Counterweights ……………………. 185
Forks …………………………….. 183
Frame – mounting ………………….. 179
Hydraulic Circuits ………………. 135,137
Mast ……………………………… 181
Frame Articulation …………………… 191
Frame – tractor …………………… 187-191
Fuel Tank and Lines …………………. 31,33
Forward and Reverse Control ………… 81-93
G
Gauges
Electric Hourmeter ………………….. 55
Fuel Sight ……………………….. 31,33
Grille …………………………… 193,195
H
Harness – electrical ………. , ……….. 49-57
Hood – tractor ……………………. 193,195
Hose and Fitting Conversion Chart ……… 202
W4 LOADER AND FORKLIFT
ALPHABETICAL INDEX
9
H
Hydraulic Circuits
· Equipment …………………….. 121-127
Forklift Lift ………………………… 135
Forklift Tilt ………………………… 137
Hydrostatic Propulsion ………………. 73
Loader Auxiliary …………………… 133
Loader Bucket …………………….. 131
Loader Lift . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Steering …………………………… 61
Hydroback – neutral centering …………… 87
Instruments – tractor …………………. 53,55
Index – numerical ……………………. 203
Index – pictoral ……………………….. 6,7
L
Lamps – instrument ……………………. 53
Levers – control (see Controls)
Loader
Buckets and Attachments ………… 173,175
Controls – hydraulic …………….. 165,167
Hydraulic Circuits ………………. 129-133
Lift Frame ………………………… 169
M
Mast – forklift ……………………….. 181
Motor – hydrostatic propulsion ………….. 79
Mounts
Engine ………………………•…. 25,27
Radiator …………………………. 13, 15
Transmission ………………………. 99
Muffler – engine exhaust ……………….. 23
N
-Neutral Start Switch and Mounting …….. 53,81
Numerical Index …………………….. 203
Neutral Centering T~be ……………. 83,85,93
0
Oil Filter- hydraulic …………. 61,125,127,155
Pallet Forks
Forklift ……. .
Loader ……. .
Panel – instrument
Parking Brake ….p
Propulsion Motor – hydrostatic drive ……… 79
Pulley – alternator· …………………….. 39
Pump
Hydraulic Equipment and Steering ……. 139
Hydrostatic Propulsion …………….. 75, 77
Pump Mounting Plates ………………. 69-71
R
Radiator – engine ……………………. 13, 15
Regulator – alternator ………………….. 39
Restriction Indicator
Air Filter …………………………. 17,19
Oil Filter ….. : ………….. ; …….. 53,155
ROPS Canopy ………………………. 199
s
Self-Leveling Linkage – loader bucket ……. 171
Seat and Seat Belts . . . . . . . . . . . . . . . . . . . . . . . . 197
Sending Units
Engine Oil Pressure ……………….. 49,51
Engine Water Temperature ………….. 49,51
Hydraulic Oil Temperature ………….. 49,51
Oil Filter Restriction ………………… 155
Shaft – drive …………………………. 103
Solenoid – starter ……………………. 41,43
Starter – engine …………………•…. 41,43
Steering
Column and Control Valve ………….. 63,65
Cylinder …………………………… 67
Hydraulic Circuit ……………………. 61
Wheel and Column ………………….. 59
Switches
Backup Alarm ………………………. 57
Key and Starter . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Neutral Start and Mounting …………. 53,81
T
Tanks
Fuel …………………………. 31,33,189
Hydraulic Oil ………………………. 189
Teeth – bucket ………………………. 173
Throttle – engine ……………………. 35,37
Transmission
Two Speed Assembly ……………. 105,107
Controls …………………………. 95,97
Mounting ………………………….. 99
Issued July, 1982
10 W4 LOADER AND FORKLIFT
ALPHABETICAL INDEX
V w
Valves Wheel – steering ………………………. 59
Check -load …………………… 145-151 Wheel and Tires ……………………… 113
Engine Oil Drain ……………………. 29 Wiring – electrical …………………… 49-57
Forklift Control ……………… 143,149-153
Loader Control …………… 141,145,147,153
Oil Cooler Bypass ………………….. 123
Oil Filter Bypass .. .. .. .. .. . .. .. .. . .. 125, 127
Relief – control valves ……………….. 153
Relief – equipment pump …………….. 139
Relief – propulsion pump ………..•…. 75,77
Steering …•………………………
