CAT Bucyrus RH120-E Hydraulic Shovel Technical Manual BI638304 – PDF DOWNLOAD

Description

CAT Bucyrus RH120-E Hydraulic Shovel Technical Manual BI638304 – PDF DOWNLOAD

FILE DETAILS:

CAT Bucyrus RH120-E Hydraulic Shovel Technical Manual BI638304 – PDF DOWNLOAD

Language : English
Pages : 130
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:

TABLE OF CONTENTS:

CAT Bucyrus RH120-E Hydraulic Shovel Technical Manual BI638304 – PDF DOWNLOAD

1 AUSTRALIAN OPTIONS..........................................  2
2 STEEL LEVER RELEASE RAD CAPS................................  4
3 PLATFORM AND STAIRCASE ASSEMBLY (LH-MKII)...................  6
4 FOLDING STAIRCASE HYDRAULICS................................ 11
5 BOOM HANDRAIL ADAPTORS...................................... 15
6 BATTERY BOX................................................. 18
7 POSITIVE BATTERY LEAD ISOLATION & STARTER LOCKOUT SYSTEM.... 20
8 GREASE SYSTEM FILTERS....................................... 22
9 SIGMA T8 AIR CONDITIONER.................................... 25
10 TRAINING SEAT.............................................. 80
11 CAB SIDE EMERGENCY LADDER.................................. 82
12 HYDRAFLOW FUEL SYSTEM...................................... 84
13 WINDOW TINTING............................................. 86
14 HOUR METER ON SERVICE ARM.................................. 88
15 MAIN CONTROL VALVE WALKWAY................................. 90
16 CABVAC 4000 VACUUM UNIT.................................... 92
17 CABVAC 4000 - FITTING INSTRUCTIONS......................... 94
18 WINDSCREEN WASHER SPRAY BAR................................ 97
19 FUEL SHUT OFF VALVE........................................101
20 H LINK GREASE SYSTEM.......................................103
21 SERVICE LEG FITTINGS.......................................105
22 CUMMINS OIL RESERVE SYSTEM.................................107
23 FVV50B4 PRESSURISER........................................129
