GENERAL

• The  instruction a have been prepared to &id in erecting a Marion 7400 Electric Walking Dragline a guide for the operator, the ground man, and the oil  in their operation, maintenance and lubrication. The engineering drawing• which accompany the machine, give the exact location of all part a, all neceaaary dimenaiona, etc.
• It is very important that extreme care be taken in aaaembly beca11ae improper erection may ca.uae unneceaaary wear and faulty operation of the machine. When the machine is ahipped from the factory, the part a are match marked throughout. Care should be taken to follow theae match mark
• • when the machine ia aaaembled. All finiahed aurfacea and bearing• are protected against corrosion and ahould be thoroughly cleaned just before aaaembly. When assembling, all bearing• ahould be lubricated. Ball and roller bearings are to be filled only 1 / Z full of the proper .
• Also lubricate all gears and put the proper oil in gear caaea up to the correct level before the machine in run. All air and electrical equipment, bearing ■ and finiahed surface• should be protected from the weather until the machine is fully asaembled.

TABLE OF CONTENTS:

CAT Dragline MARION 7400 ELECTRIC Operation And Maintenance Manual – PDF DOWNLOAD

I Erection Instructions 1 – 14
II Adjustments 1 – 12
III Operating Instructions 1 – 11
IV Lublrication Instructions 1 – 22
V Wire Rope Reeving 1 – 6
VI Electlical Instructions 1 – 26
VII Miscellaneous
