CAT Feeder Breaker 54-2122R Operation & Maintenance Manual PDF

Description

CAT Feeder Breaker 54-2122R Operation & Maintenance Manual – PDF DOWNLOAD

FILE DETAILS:

CAT Feeder Breaker 54-2122R Operation & Maintenance Manual – PDF DOWNLOAD

Language : English
Pages : 131
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:

TABLE OF CONTENTS:

CAT Feeder Breaker 54-2122R Operation & Maintenance Manual – PDF DOWNLOAD

Introduction II
Roll and Leak Testing III
Tightening and Torquing Bolts IV
Main Disassembly 1
Hub-Spindle Disassembly 2
Second Stage Carrier Disassembly 3
First Stage Carrier Disassembly 4
First Stage Carrier Sub-Assembly 5
Second Stage Carrier Sub-Assembly 9
Hub-Spindle Sub-Assembly 14
Main Assembly 21
Tool List 27
Tool Prints 28
Parts List 40
Cross-Sectional View 43

DESCRIPTION:

CAT Feeder Breaker 54-2122R Operation & Maintenance Manual – PDF DOWNLOAD

INTRODUCTION:

• This manual is a step-by-step guide to assembly and disassembly of torque-hub units.
  It is designed for the customer or shop mechanic who is repairing a particular model
  of torque-hub final drive.
• Users of this manual should note that each part mentioned is followed by an indentification
  number enclosed in parentheses. These part numbers may be referred
  to in the Parts List section of this manual and on the cross-sectional view of this
  unit.
• Any specialized tools normally used to assemble this unit are noted in the assembly
  procedures and diagrammed in the tooling section. However, it is not mandatory
  that these tools be used in this unit’s assembly. Bearing cups and cones can be pressed
  using a punch and hammer along their top edges. Seals can be pressed by laying a
  board flat on top of the seal and then hammering the board down until it meets the
  hub. Studs can be hammered into stud holes. Should you use these methods, be very
  careful not to damage parts when using a punch and/or hammer.
• Users should familiarize themselves with the procedures for roll and leak testing
  and bolt tightening and torquing found on the following two pages before getting
  started.
