DESCRIPTION:

CAT MD5090 Hydraulic Track Drill Operation & Maintenance Manual BI006830 – PDF DOWNLOAD

Safety Information:
Before Operation:

• Do study the Operator’s manual and fully understand the controls.
• Do be sure all safety guards are securely in place. Replace any damaged or missing guards.
• Do be sure all nameplates and decals pertaining to safety, operation, and maintenance are
in place and not damaged. Replace any damaged or missing nameplates or decals. Refer to decal
locator drawings in this section.
• Do be sure all personnel are clear of the machine and work area before starting the engine
or operat- ing the machine.
• Do be sure drill area is clear of all obstructions before operating machine.
• Do attach safety chain when using towbar.
• Do wear safety helmet, glasses and hearing protection when operating or working on machine.
• Do Not operate machine with:
• Hydraulic or air leaks.
• Damaged hydraulic hoses or fittings.
• Broken or damaged electrical wiring.
• Damaged or missing guards and shields.
• Damaged structural members.
• Worn or damaged mechanical parts.
• Damaged or missing fasteners.
• Broken, damaged, or malfunctioning controls.

Operation:

• Do examine the surface before drilling to determine the possible presence of unfired
explosives.
• Do provide sufficient ventilation when running the engine in an enclosed area. Exhaust
gases contain carbon monoxide, a deadly poison, which is colorless and odorless.
• Do keep work area clean and clear of mud, snow, ice, fluids, hand tools and other objects.
• Do raise the drill feed before moving the machine. Raise it high enough to allow for rough
ground or small hills. Drill feed can fall causing serious injury or death.
• Do wear seat belt and operate machine with door closed on cab machines.
• Do use PPE (personal protection equipment) appropriate for the conditions you are working
in; e.g. safety helmet, safety glasses, hearing protection, gloves, respirator and safety shoes.
• Do maintain minimum clearance from high voltage wires (see Table 1-1). Check with power
company and local regulations for specific guidelines and safety information.
• Do Not use the machine for any other purpose than what it was designed for.
• Do Not wear loose clothing or jewelry; keep clothing and hands clear of moving parts.
• Do Not travel on steep inclines, soft or unstable ground, or close to unsupported
excavations.
• Do Not move boom or machine if it is in a potentially unstable position.
• Do Not stand directly under a boom or feed.
• atmay contain explosives.

TABLE OF CONTENTS:

CAT MD5090 Hydraulic Track Drill Operation & Maintenance Manual BI006830 – PDF DOWNLOAD

INTRODUCTION
Standard Features and Options iii
Table of Contents iv
Glossary of Terms vi
Component Location viii
Optional Cab, Swing Arm and Canopy xii
SECTION 1 SAFETY
Hazard Classification 1-3
Safety Sign Symbols 1-4
Safety Information 1-7
Safety Sign List – Without Enclosure 1-9
Safety Sign Location 1-10
Safety Sign List – With Enclosure 1-13
Safety Sign Location 1-14
Safety Signs 1-16
SECTION 2 OPERATOR CONTROLS
Tramming & Positioning Controls 2-2
Instrument Panel 2-4
Drilling & Positioning Controls 2-6
Swing Arm Controls 2-8
Operator’s Cab Controls 2-10
SECTION 3 START-UP, TRAMMING & SHUTDOWN
Pre-Start Checklist 3-2
Drill Accumulators 3-4
Feed Table Pivot Pin 3-5
Engine Starting With Jumper Cables 3-7
Start-up Procedure 3-8
Cold Start Procedure 3-9
Tramming from Tram Station 3-10
Tramming from Drill Console (optional) 3-12
Swing Arm Control (optional) 3-14
Tramming from Operator’s Cab 3-16
Shutdown Checkslist 3-18
BI006830
Introduction v
Table of Contents
SECTION 4 DRILLING PROCEDURES
Loading Drill Steel – Manual Steel Rack 4-2
Loading Drill Steel – Linear Rod Changer 4-4
Drill Positioning Procedure 4-6
Drilling Procedure 4-7
Collaring Circuit (optional) 4-9
Normal Drilling 4-11
Drilling Practices 4-12
Anti-Jam System (optional) 4-14
Adding Drill Steel – Manual Rod Rack 4-16
Removing Drill Steel – Manual Rod Rack 4-16
Adding Drill Steel – Linear Rod Changer 4-18
Removing Drill Steel – Linear Rod Changer 4-21
Indexing the Swing Cylinder 4-23
HPR4519/5123 Drill Shank Replacement 4-24
HPR1H Drill Shank Replacement 4-26
SECTION 5 LUBRICATION AND TORQUE SPECIFICATIONS
Hydraulic Oils for Percussion Drills 5-2
Lubrication and Inspection 5-3
Maintenance Schedule – Moderate Climate 5-4
Maintenance Schedule – Cold Climate 5-5
Recommended Engine Oils 5-6
Daily Operational Checklist 5-7
Bolt Maintenance 5-7
Bolt Torque Specifications 5-8
Maintenance Record 5-9
