Challenger EU Hay Equipment AHC AHBT AHCT Auger Header Service Manual 79033180A

Description

Challenger EU Hay Equipment AHC AHBT AHCT Auger Header Service Manual 79033180A – PDF DOWNLOAD

IMAGES PREVIEW OF THE MANUAL:

DESCRIPTION:

Challenger EU Hay Equipment AHC AHBT AHCT Auger Header Service Manual 79033180A – PDF DOWNLOAD

OPERATOR MANUAL:

• The Operator Manual is stored in the holder (1) located on the windrower tractor. After using the Operator Manual, return the manual to the storage location. Right-hand and left-hand, as used in this manual, is determined by facing the direction the machine will travel when in use.
• The photos, illustrations, and data used in this manual were current at the time of printing, but due to possible in-line production changes your machine can vary slightly in detail. The manufacturer reserves the right to redesign and change the machine as necessary without notification.

A WORD TO THE OPERATOR:

• It is YOUR responsibility to read and understand the safety division in this manual before operating this machine. Remember YOU are the key to safety. Good safety procedures not only protect you, but also the people around you. Study the features in this manual and make them a working part of your safety program.
• Keep in mind this safety division is written only for this type of machine. Practice all other normal and customary safe working precautions, and above all REMEMBER – SAFETY IS YOUR RESPONSIBILITY.
• YOU CAN PREVENT SERIOUS INJURY OR DEATH. This safety division is intended to point out some of the basic safety situations may be found during the normal operation and maintenance of this machine, and to suggest possible ways of dealing with these situations. This division is NOT a replacement for safety procedures featured in other divisions of this manual.

PREPARE FOR OPERATION :

• Emphasize the importance of using correct procedures when working around and operating the machine. DO NOT let unqualified persons to operate your machine. Keep others, especially children, away from your area of work. DO NOT permit others to ride on the machine.
• Read and understand all operating instructions and precautions in this manual before operating or servicing the machine. Make sure you know and understand the positions and operations of all controls. Make sure the machine is in the proper operating condition as stated in this Manual.
• Make sure the machine has the correct equipment needed by local regulations. Make certain all controls are in neutral and the parking brake is engaged before starting the machine. Make certain all people are well away from your area of work before starting and operating the machine.

TABLE OF CONTENTS:

Challenger EU Hay Equipment AHC AHBT AHCT Auger Header Service Manual 79033180A – PDF DOWNLOAD

SAFETY 01
GENERAL INFORMATION 02
ELECTRICAL 03
HYDRAULICS 04
GEARBOXES 05
REEL 06
SICKLE 07
AUGER 08
HAY CONDITIONER 09
TROUBLESHOOTING 10
SPECIFICATIONS 11
INDEX 12
