DESCRIPTION:

Challenger PH13 Pickup Header Parts Manual – PDF DOWNLOAD

ALPHABETICAL INDEX
The complete alphabetical index appears at the beginning of this publication. It is used to locate major groups, assemblies and components.
NUMERICAL INDEX
The numerical index of this publication follows the Alphabetical Index at the beginning of the publication and indicates at which grid location and page number a part number appears.
ILLUSTRATIONS
All illustrations are located on the left hand page with the text on the right. Except for some common hardware, all parts are identified with an item number which corresponds to the “item” column on the text page. This is followed by the parts number, quantity and description.
HARDWARE
Common hardware not identified such as bolts, nuts, cotter pins and lube fittings, are listed indented in the text beneath the item to which they attach or fit. Common
hardware listed indented beneath an item is NOT included unless specified. Example: (Incl. BOLT, LOCKWASHER AND NUT).
ORDERING PARTS
Be sure to refer to both the text and the illustration to assure ordering the correct part.
RECOMMENDED DEALER STOCK
A recommended dealer stock listing appears at the end of this publication.

TABLE OF CONTENTS:

Challenger PH13 Pickup Header Parts Manual – PDF DOWNLOAD

INDEX
ACCESSORIES
OPTIONAL KITS PEA COULTER WHEELS 83
ADAPTER
ADAPTER ASSEMBLY CHALLENGER 660 27
ADAPTER ASSEMBLY CHALLENGER 670 29
AUGER
AUGER ASSEMBLY CHALLENGER 660 15
AUGER ASSEMBLY CHALLENGER 670 17
AUGER DRIVE & SUPPORT (RH) 11
AUGER SUPPORT (LH) 13
DECALS
DECALS AND LABELS 23
DRIVES
DRIVE SHAFT ASSEMBLY 31
ELECTRICAL
ELECTRICAL ADAPTERS 21
EXTREMITY LIGHT ASSEMBLY 19
FRAME
TABLE ASSEMBLY 9
HYDRAULICS
HYDRAULICS 25
RAKE-UP ATTACHMENT
DRAPER AND GEARBOX DRIVE 55
DRAPER AND GEARBOX DRIVE GRASS SEED PICKUP 59
DRIVE DETAIL 81
DRIVE END ROTOR 61
HOLDDOWN ASSEMBLY 53
HYDRAULIC CYLINDER ASSEMBLY MASTER SLAVE 71
HYDRAULIC HOLDDOWN 69
IDLER END ROTOR 63
MAIN FRAME ASSEMBLY 73
MAIN FRAME ASSEMBLY W/SUSPENSION SPRING UPGRADE 77
MAIN GEARBOX 65
SHIELD ASSEMBLY 67
RECOMMENDED DEALER LIST
RECOMMENDED DEALER STOCK 85
SWATHMASTER ATTACHMENT
DRAPER AND SHIELD ASSEMBLY 37
HOLDDOWN ASSEMBLY 33
HYDRAULIC CYLINDER ASSEMBLY MASTER SLAVE 51
HYDRAULIC HOLDDOWN 49
PICKUP DRIVE 41
ROLLER, TIRE, AND FRAME ASSEMBLY 35
SUSPENSION ASSEMBLY 45
SUSPENSION ASSEMBLY W/SUSPENSION SPRING UPGRADE 47
