Chery A13T Service Manual 2016 – 1.5L MT & AT Repair PDF

Description

Chery A13T Service Manual 2016 – 1.5L MT & AT Repair PDF DOWNLOAD

Description

This Chery A13T Factory Service Manual is the complete official workshop repair guide issued by Chery Automobile Co., Ltd. for 2016 A13T models equipped with the 1.5L petrol engine, available in manual (MT) and automatic (AT) variants.

Designed for professional technicians, this manual provides step-by-step diagnostic and repair procedures, factory specifications, torque values, wiring schematics, CAN communication diagrams, and detailed troubleshooting instructions. It is the same technical reference used by authorized Chery service centers.

🔍 Models Covered

• Chery A13T 1.5L MT

• Chery A13T 1.5L AT

🛠 What This Manual Covers

🔹 Engine Systems (SQRD4G15B)

• Engine mechanical overhaul procedures

• Engine management system (ECM)

• Fuel supply & emission control

• Intake, exhaust, cooling & lubrication systems

• Ignition, starting & charging systems

🔹 Transmission & Drivetrain

• QR515MHF manual transmission

• QR416AHA automatic transmission

• Clutch system

• Drive shaft, differential & axle service

🔹 Chassis & Safety Systems

• Suspension & steering (hydraulic assist)

• Brake control system (ABS)

• Brake & parking brake

• Tire & wheel specifications

• SRS (airbag) & seat belt systems

🔹 Electrical & Electronics

• Complete wiring diagrams

• CAN communication system

• Instrument cluster

• Engine immobilizer

• Lighting system

• Audio system

• TPMS (Tire Pressure Monitoring)

• Reversing radar

• Wiper & washer systems

🔹 Body & Interior

• Door lock system

• Glass & windshield

• Interior & exterior trim

• Seats & instrument panel

• Engine hood, doors & sliding roof

• Body dimensions & alignment data

📑 FULL TABLE OF CONTENTS

01. Foreword

02. Introduction

• Service Information

• How to Use This Manual

• Preparation

• Service Operation

• Vehicle Information

  • Vehicle Identification (VIN)

  • Engine Number

  • Transmission Number

• Symbols

• Circuit Diagnosis Information

  • How to Use Tester

  • ECM Control System Troubleshooting

  • Diagnosis Based on DTC

  • Diagnosis Based on Symptoms

  • Circuit Simulation Test

• Precautions for Control Module & Electrical Components

• How to Check Connector

• Circuit Information

  • How to Read Circuit Diagram

  • Circuit Diagram Index

• Abbreviation Table

03. Preparation

• Tools Overview for All Systems

04. Service Specifications

05. Maintenance

06. SQRD4G15B Engine Management System

07. SQRD4G15B Engine Mechanical

08. SQRD4G15B Fuel Supply System

09. SQRD4G15B Emission Control System

10. SQRD4G15B Intake System

11. SQRD4G15B Exhaust System

12. SQRD4G15B Cooling System

13. SQRD4G15B Lubrication System

14. SQRD4G15B Ignition System

15. SQRD4G15B Starting System

16. SQRD4G15B Charging System

17. QR515MHF Manual Transmission

18. QR416AHA Automatic Transmission

19. Clutch

20. Drive Shaft

21. Differential

22. Axle

23. Suspension

24. Tire and Wheel

25. Brake Control System

26. Brake System

27. Parking Brake

28. Steering Column

29. Hydraulic Assist Steering

30. Air Conditioning

31. Supplemental Restraint System (SRS / Airbags)

32. Seat Belt System

33. Engine Immobilizer System

34. Constant Speed Cruise System

35. Lighting System

36. Wiper and Washer

37. Door Lock System

38. Instrument Cluster

39. Audio System

40. Reversing Radar System

41. Tire Pressure Monitoring System (TPMS)

42. Horn

43. Other Systems

44. Windshield / Window Glass

45. Rear View Mirror

46. Instrument Panel

47. Seat

48. Engine Hood / Door

49. Exterior

50. Interior

51. Sliding Roof

52. Body Dimensions

53. CAN Communication

54. Matching

55. Wire Harness

➡ Total sections: 55+ detailed chapters
