Foreword

• In this first part of the Operator’s Manual information is given on Operation, Specifications and Lubrication of the CLAAS-High Density Balers.
• The second part of the Operator’s Manual covers the chapters General Information, Maintenance and provides additional practical information concerning the efficient operation of your CLAAS – High Density Baler. Use that manual as your guide to obtain best results from your Baler.
• Follow our recommendations regarding the correct operation and lubrication of the machine. Neglect in maintenance or faulty adjustments of the machine will result in inefficiency and loss of valuable time.
• It is therefore recommended, that an authorised CLAAS – Dealer carries out the regular maintenance operations, to ensure that your CLAAS-High Density Baler will function for many years and always be ready for immediate use.

IMPORTANT

• The instructions contained in this manual should be carefully read and observed by all persons who are concerned with the operation, maintenance and inspection of this machine, in order to prevent accidents.
• Especially the SAFETY RULES and the group PRIOR TO OPERATION in this manual should be read with the utmost care and adhered to.
• The use of spare parts, accessories and ancillary equipment, which are not originally manufactured by CLAAS, can change the specified design characteristics of the CLAAS machine or can detract from its functional performance, with a possible adverse affect on the active and/or passive operational safety of the machine and its occupational safety standards (accident prevention).
• CLAAS are in no way liable for any damage or personal injury caused through the use of other than original or approved CLAAS parts, accessories and ancillary equipment.

TABLE OF CONTENTS:

CLAAS 65/55/52 Part 1 Operation Specifications Lubrication Operator’s manual – PDF DOWNLOAD

Identification plate, serial number 5
Safety rules 6
Specifications 9
1 Before operation
Knotter discs 12
Chain 12
Baler hook-up 12
Universal drive shaft 13
Drawbar jack and universal drive-shaft support 13
Baler twine 13
Setting safety lock to OFF 13
Threading twine 15
Setting safety lock to ON 15
Clevis hitch 15
2 Operation
Bale chute, loading chute, bale thrower, 22
Baler drawbar 22
Shifting the baler to working position 22
Pick-up 22
Pick-up lift 23
Hydraulically operated pick-up lift 23
Bale density, MARKANT 55/52 23
Bale density, MARKANT 65 24
Bale length 24
Bale counter 24
3 After operation
After a day’s work 32
Shifting thebaler to transport position 32
Unhitching the baler 32
4 Lubrication
Lubricants chart 43
Lubrication chart 43
