Introduction

These instructions describe the installation of the twine wrapping system, Standard/Comfort, to baler types ROLLANT 250 and ROLLAND 250 RC. You find the list of required parts on pages

TABLE OF CONTENTS:

CLAAS Baler ROLLANT 250 250 ROTO CUT CLAAS-Twine wrapping system StandardComfort Fitting Instructions Manual_DE_EN_FR

Required parts
Twine wrapping system, pre-assembled
Covering
Hexagon bolt M6x20SB
Contact washer A6
Idler pulley, pre-assembled
Washer13x40x6
Hexagon bolt M12x11 0
Spacer bush
Washer13x22x3
Locking nut VM12
Washer 16,5x33x3
Washer 12,2x30x5
Shim 17x35xO,5
Shim 18,5x27xO,3
Spacer tube
Idler pulley, pre-assembled
Hexagon bolt M12x60
Washer13x22x3
Drawing hook
Tension spring 2,5x18x154
V-belt 13x8x3500LI
Shaft
Bush D30H9x60
Dowel pin 5x32A
Dowel pin 3x30B
V-belt pulley, pre-assembled
Spring pin 3×77
Tapered grease nipple AS 6×1
Adjustment ring A20E 8x35x10/M8
Stud M8x10
Sticker 515 165.0
Sticker 515 387.0
Sticker 515 212.0
Twine box, pre-assembled
Bracket
Hexagon bolt M8x20
Contact washer A8
Hexagon nut M8
Bow
Hexagon bolt M8x20
Contact washer A8
Hexagon nut M8
Tube clamp
Hexagon bolt M6x60
