CLAAS COMBIENES DOMINATOR 130 Hydraulic SYSTEM TECHINCAL MANUAL – PDF DOWNLOAD

Description

CLAAS COMBIENES DOMINATOR 130 Hydraulic SYSTEM TECHINCAL MANUAL – PDF DOWNLOAD

FILE DETAILS:

CLAAS COMBIENES DOMINATOR 130 Hydraulic SYSTEM TECHINCAL MANUAL – PDF DOWNLOAD

Language : English
Pages :100
Downloadable : Yes
File Type : PDF
Size:3.98 MB

TABLE OF CONTENTS:

CLAAS COMBIENES DOMINATOR 130 Hydraulic SYSTEM TECHINCAL MANUAL – PDF DOWNLOAD

1 Overall hydraulic system1-1

2 Steering hydraulics / 3-D sieve pan control system 2-1
3 Working hydraulics 3-1
4 Position of components R-1
Index index-1
1 Overall hydraulic system 1-1
11 Hydraulic system – General 1-3
111 Hydraulic pumps 1-4
112 Oil filter head 1-6
12 Overall hydraulic system circuit diagram 1-9
121 Overall hydraulic system circuit diagram  Machine with grain tank 1-12
122 Overall hydraulic system circuit diagram  Machine with bagging platform 1-16
111 Hydraulic pumps 1-4
112 Oil filter head 1-6
21 Steering hydraulics circuit diagram without AUTOPILOT 2-4
22 Steering hydraulics circuit diagram with AUTOPILOT 2-8
23 Steering valve unit 2-10
24 Function of steering 2-12
25 Checking the steering 2-16
26 AUTOPILOT solenoid valve 2-18
27 Checking the AUTOPILOT system 2-20
28 3-D sieve pan control system 2-22
31 Working hydraulics circuit diagram 3-4
32 Pressure relief valve 3-6
321 Pressure relief valve (703) – Machine with grain tank 3-6
322 Pressure relief valve – Machine with bagging platform 3-8
33 Swinging the grain tank unloading tube 3-10
4/3 way valve 3-10
Hydraulic cylinder 3-12
34 Lock-up valve unit 3-14
35 Flow divider (option) – for horizontal reel adjustment and/or straw collector 3-16
36 Reverse front attachment 3-18
3/2-way valve (Y86) 3-18
Hydraulic cylinders 3-20
37 Horizontal reel adjustment 3-22
4/3-way valve 3-22
Hydraulic rams 3-24
38 Raise / lower front attachment, variator variable-speed drive, vertical reel adjustment,
threshing drum variable-speed drive 3-26
6/9-way multi-function valve 3-26
Vertical reel adjustment hydraulic cylinder 3-28
Variator variable-speed drive, threshing drum variable-speed drive hydraulic cylinder 3-30
Rotary coupling and throttle non-return valve 3-32
39 Variator foot valve 3-34
