DESCRIPTION :

CLAAS DISCO 3000 TC Plus DISCO 3000 Flapgrouper / Plus DISCO 3000 TRC / Plus DISCO 3000 AS / Plus Drawbar conversion kit Conversion instructions Manual_DE_EN_FR

INTRODUCTION These instructions describe a safe and timesaving procedure for the conversion kit ET-No. 925 544.0 (drawbar). Please read this manual thoroughly before starting work! Pay particular attention to the section »General instructions«. The following machines can be converted:

CLAAS disc mower types:
DISCO 3000 TC Plus
DISCO 3000 Flapgrouper / Plus
DISCO 3000 TRC / Plus
DISCO 3000 AS / Plus

The shipping package is listed on page 4.2. Before starting with the work, ensure that all parts of the conversion kit have been supplied. The “Shipping package” list is also considered a supplement to the spare parts list. Components, which are not needed for the conversion, must be disposed of in an environmentally compatible manner.
TABLE OF CONTENTS:

CLAAS DISCO 3000 TC Plus DISCO 3000 Flapgrouper / Plus DISCO 3000 TRC / Plus DISCO 3000 AS / Plus Drawbar conversion kit Conversion instructions Manual_DE_EN_FR

1. Introduction
Introduction ……………………………………………………………………. 1.1
2. Table of contents
3. General instructions
Of special importance ……………………………………………………… 3.1
Identification of warnings and dangers ………………………………. 3.1
Designated use ………………………………………………………………. 3.2
Safety decals with warning symbols ………………………………….. 3.2
General safety instructions ………………………………………………. 3.2
4. Shipping package
Shipping package for drawbar conversion kit ……………………… 4.2
Conversion kit: 925 544.0 …………………………………………… 4.2
5. Disassembly
Drive shaft …………………………………………………………………….. 5.2
Protective plates …………………………………………………………….. 5.2
Hydraulic hoses and cables ……………………………………………… 5.2
6. Welding instructions
Drive shaft bearing support ……………………………………………… 6.1
Drawbar reinforcement ……………………………………………………. 6.2
7. Reassembly
Hydraulic hoses and cables ……………………………………………… 7.1
Protective plates …………………………………………………………….. 7.1
Drive shaft …………………………………………………………………….. 7.2
Check and observe the following points before putting into
operation: ………………………………………………………………………. 7.3
