Claas DISCO 3450 PLUS 3050 / 3050 PLUS 3050 C PLUS 2650 / 2650 PLUS 2650 C PLUS Operator’s Manual

Description

Claas DISCO 3450 PLUS 3050 / 3050 PLUS 3050 C PLUS 2650 / 2650 PLUS 2650 C PLUS Operator’s Manual

DESCRIPTION:

Claas DISCO 3450 PLUS 3050 / 3050 PLUS 3050 C PLUS 2650 / 2650 PLUS 2650 C PLUS Operator’s Manual

INTRODUCTION

This operator’s manual is the original operator’s manual. Hereafter, it is referred to simply as the operator’s manual. This operator’s manual contains information on the use, adjustment and operation of the mower unit. The advice on care and maintenance should be followed in order to ensure that the machine is always ready for operation and will have a long service life. Also, have assembly of your machine and regular inspections carried out by your specialist workshop. Failure to carry out maintenance work, or incorrect operation will result in poor machine efficiency and loss of valuable time. Make use of the experience and latest knowledge embodied in this machine by operating and maintaining it properly, then your cutting mechanism, mower unit will always produce good results
TABLE OF CONTENTS:

Claas DISCO 3450 PLUS 3050 / 3050 PLUS 3050 C PLUS 2650 / 2650 PLUS 2650 C PLUS Operator’s Manual

1 Introduction
Introduction 11
VALIDITY 11
3 Preface
Of special importance 31
Identification plate 31
4 Safety Rules
Identification of warning and danger signs 41
Designated use 41
Avoidable incorrect applications 42
General safety and accident prevention
regulations 42
Attached machines 43
Trailed machines 44
PTO operation 44
Hydraulic system 44
Tyres 45
Maintenance 45
Sound pressure level 45
De-commissioning and disposal 46
Safety decals with pictorials 47
5 Specifications
Specifications 51
Axial loading, minimum ballast and total weight
calculation 51
Noise pressure level of the disc mowers DISCO
3450 / 3050 / 3050 C / 2650 / 2650 C 55
6 Prior to operation
Loading / unloading the machine DISCO
3450 / 3050 / 3050 C / 2650 / 2650 C 61
Check and observe the following before putting into
operation! 62
Attachment to the tractor 63
Adjusting the hitch 63
Adjust universal drive shaft 65
Fitting the universal drive shaft 65
Universal drive shaft – conditioner 67
Hydraulics 67
Stand 69
Fitting the machine 610
Prior to transportation 611
Driving on public roads 614
Identification of the machine for road traffic 614
7 Operation
Operation 71
Working position 71
Safety devices 73
Transport position 73
Setting the cutting height 74
Collision protection 75
Mowing 76
Recommendations for environmental
protection 79
Suspension springs 711
Swath device
Right hand swath disc 712
Left hand swath disc
(Optional equipment
DISCO 2650 Plus / 2650) 714
Left hand swath disc
(Optional equipment
DISCO 3050 Plus / 3050) 716
Conditioner
DISCO 3050 C / 2650 C 716
Swath plates
DISCO 3050 C / 2650 C 717
Wide distribution hood
(Optional equipment DISCO 3050 C Plus /
2650 C Plus) 717
Additional equipment 718
High cutting runners B03 0020 718
Additional runners C03 0030 718
Collision protection and safety frame
S03 0070 718
Left hand swath disc G03 0020 718
Left hand swath plate G03 0030 719
Changeover kit for PTO speed 1000 rpm
P09 0010 719
Wide distribution hood G03 0010 720
Slip yoke kit M03 0010 720
Slip yoke kit M03 0020 720
Hydraulic connecting parts for
tractor R03/0010 720
Lighting adapter (USA, R03/0500) 721
8 Maintenance
Important maintenance instructions 81
Hydraulic system 81
Energy accumulators 81
Bolts 81
Lubrication 81
Safety device (safety frame) 82
Drive systems 83
Tensioning the drive belts 83
Conditioner gearbox 86
Mower head 87
Knife sections 89
Knife section box 810
Changing the cutting knives 811
Blade replacement DISCO 3050 / 2650 817
Mower discs 819
Replacing cutting discs 819
Mower head suspension 821
Conditioner tines 823
Fitting/removing tines 823
Table of contents
22 BA DISCO 3450 / 3050 / 3050 C / 2650 / 2650 C – 00 293 857 6
Table of contents
Universal drive shaft 823
Hydraulic system 824
Hydraulic hose connections 824
Hydraulic cylinders 824
Connecting elements 825
Screw connections 825
Cleaning and care 825
Winter storage 826
Malfunctions 826
9 Lubrication chart
Safety rules 91
Lubricants 91
Lubrication 91
