Claas DISCO 8550 AS PLUS Operator’s Manual & Spare Parts List Manual – PDF DOWNLOAD

Description

Claas DISCO 8550 AS PLUS Operator’s Manual & Spare Parts List Manual – PDF DOWNLOAD

DESCRIPTION:

Claas DISCO 8550 AS PLUS Operator’s Manual & Spare Parts List Manual – PDF DOWNLOAD

INTRODUCTION:

This operator’s manual contains additional information for the DISCO operator’s manual. It provides you with information on adjustment and maintenance of the swath grouper. It also contains a spare parts list for the swath grouper. Please refer to the DISCO operator’s manual 188 612.4 for information regarding use, adjustment and operation of the CLAAS disc mower.

• Follow the advice on correct maintenance and servicing in order to ensure maximum performance and a long service life of your machine. Also, have assembly of your machine and regular inspections carried out by your specialist workshop.
• Failure to carry out maintenance work, or incorrect operation will result in poor machine efficiency and loss of valuable time. By ensuring correct operation, and carrying out maintenance and service work with care, you will be able to make full use of state-of-the-art technology and of the experience with which your machine has been designed.

TABLE OF CONTENTS:

Claas DISCO 8550 AS PLUS Operator’s Manual & Spare Parts List Manual – PDF DOWNLOAD

1 Introduction
Introduction 1 1
2 Contents
3 Preface
Of special importance 3 1
4 Safety Instructions
Identification of warnings and danger signs 4 1
Safety decals with warning symbols 4 1
5 Specifications
DISCO 8550 AS Plus 5 1
6 Before Operation
Use as a front/rear combination unit 6 1
Mounting the swath grouper 6 1
Hydraulics installation 6 4
Check and observe the following before putting into
operation! 6 8
7 Operation
Operation 7 1
Function of swath grouper 7 1
Before mowing 7 1
Setting the swath groupers 7 2
Ejection range 7 2
Ejection direction 7 2
Ejection height 7 3
Swath formation 7 3
8 Maintenance
Important Maintenance Instructions 8 1
Hydraulic system 8 1
Bolts 8 1
Lubrication 8 1
Protective devices (safety frame) 8 1
DRIVE SYSTEMS 8 2
Conveyor belt tension 8 2
Hydraulic system 8 2
Hydraulic hose connections 8 2
9 Spare parts list
Lateral unit for cross conveyor 9 3
Arm / compensating spring 9 5
Cross conveyor 9 7
Hydraulic system 9 9
