CLAAS DISCO 8550 C PLUS DISCO 3050 FC PLUS DISCO 3050 FC Crop spreader FITTING INSTRUCTIONS MANUAL_DE_EN_FR_IT_ES

Description

CLAAS DISCO 8550 C PLUS DISCO 3050 FC PLUS DISCO 3050 FC Crop spreader FITTING INSTRUCTIONS MANUAL_DE_EN_FR_IT_ES

DESCRIPTION:

CLAAS DISCO 8550 C PLUS DISCO 3050 FC PLUS DISCO 3050 FC Crop spreader FITTING INSTRUCTIONS MANUAL_DE_EN_FR_IT_ES

INTRODUCTION

These instructions describe a safe and timesaving procedure for the installation of the conversion kits Part-No. 923 645.0 (DISCO 8550 C Plus) Part-No. 923 644.0 (DISCO 3050 FC Plus / 3050 FC). Please read this manual thoroughly before starting work! Pay particular attention to the »General instructions « section. The following machines and devices can be converted:

Disc mowers:
DISCO 8550 C Plus
from machine no. 652 0 1811
DISCO 3050 FC Plus / 3050 FC
from machine no. 651 0 2931

The shipping package is listed on page 4.2. Before starting work make sure that the mounting kit is complete. The “Package list” list is also considered a supplement to the spare parts list. Dispose of old parts that are not required for the assembly in an environmentally correct manner.
TABLE OF CONTENTS:

CLAAS DISCO 8550 C PLUS DISCO 3050 FC PLUS DISCO 3050 FC Crop spreader FITTING INSTRUCTIONS MANUAL_DE_EN_FR_IT_ES

1 Introduction
Introduction 11
2 Table of contents
3 General instructions
Of special importance 31
Identification of warnings and dangers 31
Designated use 32
Safety decals with warning symbols 32
General safety instructions 32
4 Package list
Shipping package DISCO 8850 C Plus 42
Mounting kit: 923 6450 42
Shipping package DISCO 3050 FC Plus / 3050 FC 43
Mounting kit: 923 6440 43
5 Mounting the crop spreader
Mounting the deflector plates 51
DISCO 8550 C Plus 51
DISCO 3050 FC Plus / DISCO 3050 FC 52
Check and observe the following before putting into operation 53
