DESCRIPTION:

CLAAS Dominator VX 108 VX 98 VX 88 CLAAS-Straw Walker Ball Bearings Fitting Instructions Manual_DE_EN_FR

INTRODUCTION

These fitting instructions show you the installation of the straw walker ball bearings on the

CLAAS combines
DOMINATOR VX 108
DOMINATOR VX 98 and
DOMINATOR VX 88

The shipping package is shown on page 5. Each part has a number. The part specification e.g. for bolts is also stated in the «shipping package». The list gives the dimensions and the quantity of the bolts as well as the parts belonging to it, like nuts and Contact washers. Text and pictures apply, in general to all the machine types covered by this book and the information given applies equally, except where reference is made to a particular model in captions to the pictures or in the main text
TABLE OF CONTENTS:

CLAAS Dominator VX 108 VX 98 VX 88 CLAAS-Straw Walker Ball Bearings Fitting Instructions Manual_DE_EN_FR

1 Straw walker shaft, front 1
2 Straw walker shaft, rear 1
3 Hexagon head bolt M 8 x 20 DIN 933-88
Contact washer A 8
Hex nut M 8 DIN 934-8
DOMINATOR VX 108 48
DOMINATOR VX 98 and VX 88 40
