Claas Forage Harvesters JAGUAR 880 – 820 Repair Manual – PDF DOWNLOAD

Description

Claas Forage Harvesters JAGUAR 880 – 820 Repair Manual – PDF DOWNLOAD

IMAGES OF MANUAL:

TABLE OF CONTENTS:

Claas Forage Harvesters JAGUAR 880 – 820 Repair Manual – PDF DOWNLOAD

FEED UNIT
Removing the feeder housing 4. 1
Fitting the feeder housing 4. 3
Removing the gearbox for the upper rollers 4. 4
Dismantling the gearbox for the upper rollers 4. 5
Assembling the gearbox for the upper rollers 4. 8
Fitting the gearbox for the upper rollers 4. 9
Removing the pressure roller 4. 10
Dismantling the pressure roller 4. 11
Assembling the pressure roller 4. 13
Fitting the pressure roller 4. 13
Removing the compression roller 4. 15
Assembling and fitting the compression roller 4. 17
Removing the chain housing for the
feeder roller drive 4. 20
Dismantling the chain housing 4. 20
Removing the chain housing bearing rings 4. 21
Assembling and fitting the chain housing
for the feeder roller drive 4. 23
Dismantling the clutch 4. 23
Assembling the clutch 4. 25
Removing the feeder roller magnetic boxes 4. 25
Dismantling the feeder roller magnetic boxes 4. 26
Assembling the feeder roller magnetic boxes 4. 29
Fitting the feeder roller magnetic boxes 4. 30
Removing the smooth roller 4. 31
Fitting the smooth roller 4. 33
Tensioning the tension springs
for the compression/pressure roller 4. 34
GEARBOX / REVERSER GEAR
Removing the shut-off mechanism 4. 35
Fitting the shut-off mechanism 4. 37
Adjusting the solenoid 4. 38
Removing the gearbox / reverser gear 4.39/2
Removing and dismantling the drive crown 4.42/2
Assembling the drive crown 4.47/2
Dismantling the gearbox / reverser gear 4.48/2
Assembling the gearbox / reverser gear 4.63/2
Fitting the gearbox / reverser gear 4.94/2
