CLAAS JAGUAR 880-820 Side screen wash wiper Fitting Instructions Manual _DE_EN_FR – PDF DOWNLOAD

Description

CLAAS JAGUAR 880-820 Side screen wash wiper Fitting Instructions Manual _DE_EN_FR – PDF DOWNLOAD

DESCRIPTION:

CLAAS JAGUAR 880-820 Side screen wash wiper Fitting Instructions Manual _DE_EN_FR – PDF DOWNLOAD

INTRODUCTION

These fitting instructions explain the procedure for installing the Side Screen Wash Wiper to the CLAAS Forage Harvester JAGUAR 880 – 820. On page 4 can be found the list of components required for the conversion. The numbers refer to the quantities required. Each major component is identified with a number. Each major component such as a bolt should be checked against the list of supplied components in order to determine quantity and relative components such as nuts and washers. The text and pictures are as accurate as possible. To determine the difference between different types of components, then please refer to the text description.
TABLE OF CONTENTS:

CLAAS JAGUAR 880-820 Side screen wash wiper Fitting Instructions Manual _DE_EN_FR – PDF DOWNLOAD

1 Door right hand 1
2 Door left hand 1
3 Mounting plate welded 1
4 Shim 1
5 Cable channel 385 long 2
6 Cable channel 710 long 2
7 Double sided tape 12 x 15 1
8 Nozzle holder 82 x 40 x 15 2
9 PVC-hose 4 x 6 x 3750 long 1
10 PVC-hose 4 x 6 x 5500 long 1
11 Grommet A 10 x 135 x 4 6
12 Corrugated plastic tube NW 10 x 90 long 2
13 Corrugated plastic tube NW 10 x 500 long 2
14 Cable band min 47 x 188 long 12
15 Rivet A 4 x 8 8
16 Nozzle 2
17 Bracket 2 x 1895 x 422 1
18 Slotted-rivet nut M 8 4
19 Hex bolt M 8 x 20 DIN 933-88 4
Contact-washer A 8 4
20 Electric pump 1
21 Adapter ring 1
22 Container with pump 1
23 Strap 2 x 30 x 550 1
24 Hex bolt M 8 x 30 DIN 933-88 2
Contact-washer A 8 2
Lock nut VM 8 2
25 Wiring loom — current supply 1
26 Spade fuse DIN 72581 — C 15 1
27 Socket head screw M 5 x 10 DIN 84 1
Spring washer 5 1
Hex nut M 5 DIN 934 1
28 Relay 12 V 1
29 Wiring loom — motors 1
30 Pipe clamp RS 112/20 2
31 Side wiper motor 2
32 Rubber washer 14 x 50 x 2 4
33 Rubber washer 142 19 x 3 4
34 Washer 16,5 x 50 x 1,5 4
35 Hex nut M 16 x 1 2
36 Cap 22 x 405 2
37 Cap 2
38 Wiper arm 2
39 Wiper blade 2
40 Washer 6,2 x 15 x 15 4
41 Rubber washer 5 x 19 x 3 4
42 Rubber washer 52 x 10 x 25 4
43 Hex bolt M 6 x 20 DIN 933-88 2
44 Hex guard cap M 6 GPN 1000 2
45 Side wiper cap left hand 1
46 Flat head bolt with gab M 6 x 12 2
47 Rocker switch 2
48 Insert 2
49 Side wiper cap right hand 1
