CLAAS LEXION 410/405 CLAAS-Straw Chopper Fitting Instructions Manual_DE_EN_FR

Description

CLAAS LEXION 410/405 CLAAS-Straw Chopper Fitting Instructions Manual_DE_EN_FR

DESCRIPTION:

CLAAS LEXION 410/405 CLAAS-Straw Chopper Fitting Instructions Manual_DE_EN_FR

INTRODUCTION

• This manual provides instructions for fitting the Straw Chopper to the CLAAS LEXION 410 / 405 combines.
• The shipping package is specified on pages 8 and 9
• The numbering corresponds to the order of installation.
• CLAAS Service Department.

TABLE OF CONTENTS:

CLAAS LEXION 410/405 CLAAS-Straw Chopper Fitting Instructions Manual_DE_EN_FR

1 Chopper 1
2 Hexagon bolt
M 10 x 25 DIN 933-8 8 6
Hexagon nut M 10 6
Contact washer A 10 6
3 Guide plate 1
4 Hexagon bolt
M 8 x 20 DIN 933-8 8 6
Contact washer A 8 6
Hexagon bolt
M 10 x 30 DIN 933-8 8 2
Contact washer A 10 2
Adapter 2
Rubber fabric, complete 1
Lock nut VM 6 10
Washer 6 4 10
5 Bracket 1
6 Bracket 1
7 Hexagon nut M 8 4
8 Spring-loaded cylinder 2
9 Lock nut VM 10 4
Washer 10 5 x 25 x 2 4
10 Limit switch 1
11 Hexagon bolt
M 6 x 20 DIN 933-8 8 2
Hexagon nut M 6 2
Contact washer A 6 2
12 Cable clamp 1
13 Magnetic pick-up 1
14 Pipe clamp 1
15 Cable clamp 1
16 Deflector assembly (left-hand) 1
Deflector assembly (right-hand) 1
17 Hexagon bolt
M 8 x 20 DIN 933-8 8 4
Contact washer A 8 4
18 Washer 10 5 x 22 x 1 2
19 Cotter pin 2 x 18 2
20 O-Ring 2
21 LP valve 1
22 Hydraulic hose 1
23 Hydraulic cylinder 1
24 Mounting plate 1
25 Mounting plate 1
26 Hexagon bolt
M 8 x 25 DIN 933-8 8 2
Contact washer 2
27 Jockey pulley arm 1
28 Set collar 2
29 Power band belt 1
30 Cylinder pin D 10 x 5 1
31 Clamp 1
32 Hexagon bolt M 6 x 12 1
Contact washer A 6 1
33 Hose 1
34 Hollow screw 2
Seal 4
35 Hollow screw 1
36 Pipe clamp 1
37 Bracket 1
38 Hexagon bolt M 6 x 30 2
Contact washer A 6 2
Hexagon nut M 6 2
39 Support 1
40 Hexagon bolt M 10 x 25 3
Contact washer 3
41 Spacer bushing 1
42 V-belt pulley 1
43 V-belt 1
44 Belt guide 1
45 Mounting bracket 6
46 Mushroom head bolt M 8 x 20 6
Contact washer 6
Nut 6
47 Hexagon bolt M 8 x 75 2
Contact washer A 8 2
Hexagon nut M 8 2
48 Spacer tube 2
49 Rubber cushion 1
Contact washer A 8 2
Hexagon nut M 8 1
50 Hexagon bolt M 8 x 12 1
51 Brace 1
52 Hexagon bolt
M 16 x 110 DIN 931-8 8 1
Contact washer A 16 1
53 Hexagon bolt
M 16 x 80 DIN 931-8 8 1
Contact washer A 16 1
54 Chopper intermediate drive unit 1
55 Hexagon bolt
M 10 x 45 DIN 931-8 8 4
Contact washer A 10 4
56 V-belt 1
57 Jockey pulley arm 1
58 Set collar 2
59 Spring-loaded cylinder 1
60 Hexagon bolt M 8 x 25 2
Contact washer A 8 2
61 Pin 1
62 Cotter pin 4 x 22 1
63 Guard 1
64 Hexagon nut M 8 2
Contact washer A 8 2
65 Jockey pulley 1
66 Pin 1
67 Cotter pin 4 x 22 1
68 Lock bolt
M 10 x 50 DIN 931-8 8 1
Spacer tube 1
Contact washer A 10 1
Hexagon nut M 10 1
69 Jockey pulley 1
70 Hexagon dowel screw
M 16 x 120 DIN 7968 1
Contact washer A 16 1
Hexagon nut M 16 1
Spacer bushing 1
71 Hinge plate 2
72 Mounting plate 2
73 Hexagon bolt
M 8 x 16 DIN 933-8 8 4
Hexagon nut M 8 4
Contact washer A 8 4
74 Door 1
75 Wire rope 1
76 Hexagon bolt
M 10 x 30 DIN 933-8 8 2
Contact washer A 10 2
77 Safety frame 1
78 Hexagon bolt M 12 x 65 2
Contact washer A 12 2
Hexagon nut M 12 2
79 Hexagon bolt
M 8 x 20 DIN 933-8 8 4
Contact washer A 8 4
Hexagon nut M 8 4
80 Cheese-head screw
M 8 x 40 DIN 912 2
Hexagon nut M 8 2
Contact washer A 8 2
