 INTRODUCTION

These instructions describe the safe and timesaving work sequence for retrofitting the cab heater. Retrofitting of the LEXION 460-410 combine harvesters, with the supplementary kit part no. 546 604.0, is possible from the following machine number ranges: 54300011, 54400011, 55300800, 55400800 and 55700800. The standard mounting time is approx. 4 man hours. See page 4.1 for the shipping package. Observe the »Safety Rules« in the applicable operator’s manual.

General
information
IMPORTANT

• The instructions contained in this manual should be carefully read and observed by all persons who are concerned with the operation, maintenance and inspection of this machine/ front attachment in order to prevent accidents. Especially the »Safety Rules« in the operator’s manual should be read with the utmost care and adhered to.
• In addition, please also observe the accident prevention regulations that apply for your own country. Before commencing with the job, ensure that all the tools and service aids are available. Compare existing machine type/front attachment type with the list in the chapter »Shipping Package« and the parts kit supplied. The specification of the components, e.g. bolts, is shown on the shipping package.
• The shipping package shows the position number (pos. no.) of the components. Parts such as nuts and contact washers do not have a position number but belong to the bolt listed above which does have a position number. Additional part specifications are the part no., description, measurements, DIN and the quantity. In order to help with the assembly, existing components in the instructions are identified with letters, whereas new parts have been identified with a number (position number).
• Texts and pictures apply, in general, to all machine types covered by this book and the information given applies equally, except where reference is made to a particular model in captions to the pictures or in the main text. Technical data, dimensions and weights are given as an indication only. CLAAS reserve the right to make changes subsequently as technical developments continue. Responsibility for errors or omissions not accepted. Front, rear, right and left refer to the direction of forward travel.

TABLE OF CONTENTS:

CLAAS LEXION 460 – 410 Cab Heater Fitting Instructions Manual – PDF DOWNLOAD

CONTENTS
1 Introduction
Introduction 11
2 Contents
Contents 21
3 General
information
Important 31
Identification of warnings and danger signs 32
Correct use 32
4 Shipping Package
Shipping Package 41
Supplementary kit 546 6040 41
5 Installation
Fitting the cab heater 51
Preparing the installation 51
Opening the cab roof 51
Installing the radiator (1) 52
Installing the turn switch (16) 54
Installing rope (18) 54
Adjusting rope (18) 55
Routing hose lines (11) and (12) in the grain tank 56
Draining the coolant 57
Routing hose lines (11) and (12) in the
engine compartment 58
Heater feed line 58
Heater return line 58
Filling up cooling liquid 59
Test run 59
