DESCRIPTION:

CLAAS LEXION 480 – 410 Fitting Instructions Manual – PDF DOWNLOAD

INTRODUCTION
These instructions describe the safe and timesaving work sequence for retrofitting the yield meter. The 3-D equipment is required for the supplementary kit, parts no. 014 610.1. Without the 3-D equipment, supplementary kit 683 025.1 is additionally required.
Retrofitting of the LEXION 480-410 combine-harvesters is possible from the following machine number ranges: 54300011, 54400011, 54500011, 54600011, 54700011, 54800011.
The standard mounting time is approx. 4.75 man hours
for machines with 3-D equipment and approx. 6.25
man hours for machines without 3-D equipment.
See page 4.1 for the shipping package.
Observe the «Safety Rules» in the applicable operating instructions.

• The instructions contained in this manual should be carefully read and observed by all persons who are concerned with the operation, maintenance and inspection of this machine/ front attachment in order to prevent accidents. Especially the «Safety Rules» in the operator’s manual should be read with the utmost care and adhered to.
• In addition, please also observe the accident prevention regulations that apply for your own country. Before commencing with the job, ensure that all the tools and service aids are available. Compare existing machine type/front attachment type with the list in the chapter «Shipping Package » and the parts kit supplied.

TABLE OF CONTENTS:

CLAAS LEXION 480 – 410 Fitting Instructions Manual – PDF DOWNLOAD

1 Introduction
Introduction 1 1
2 Contents
Contents 2 1
3 General information
Important 3 1
Identification of warnings and danger signs 3 2
Correct use of combine 3 2
4 Shipping Package
Shipping Package 4 1
Supplementary kit 014 610 1 when the 3-D equipment is
available and additionally 683 025 1without 3-D 4 1
5 Installation
Installing the yield meter 5 1
Preparing the installation 5 1
Installing the LEM yield sensor with accessories 5 1
Attaching the fitted hydraulic chain tensioner 5 3
Removing brace (L) of the chain tensioner 5 3
Pre-assembling the new chain tensioner device 5 3
Mounting the chain tensioner device 5 3
Installing assembled moisture sensor (1) 5 4
Laying low-pressure lines for machines without 3-D 5 5
Creating a vacuum in the hydraulic oil tank 5 5
Removing the fuel tank on machines LEXION 480-440
for hose routing 5 5
Hydraulic connections for machines with 3-D 5 8
Hydraulic connections for machines with 3-D 5 9
Hydraulic connections for machines with/without 3-D 5 9
Pre-assembling and installing the inclinometer 5 10
Routing the LEM cable loom with accessories and
installing the LEM module 5 10
Preparing and performing a test run 5 17
