CLAAS LEXION 480 – 410 Yield meter Fitting Instructions Manual_DE_EN_FR – PDF DOWNLOAD

Description

CLAAS LEXION 480 – 410 Yield meter Fitting Instructions Manual_DE_EN_FR – PDF DOWNLOAD

DESCRIPTION:

CLAAS LEXION 480 – 410 Yield meter Fitting Instructions Manual_DE_EN_FR – PDF DOWNLOAD

INTRODUCTION

These instructions describe the safe and timesaving work sequence for retrofitting the yield meter. The 3-D equipment is required for the supplementary kit, parts no. 014 610.1. Without the 3-D equipment, supplementary kit 683 025.1 is additionally required. Retrofitting of the LEXION 480-410 combine-harvesters is possible from the following machine number ranges: 54300011, 54400011, 54500011, 54600011, 54700011, 54800011. The standard mounting time is approx. 4.75 man hours for machines with 3-D equipment and approx. 6.25 man hours for machines without 3-D equipment. See page 4.1 for the shipping package. Observe the «Safety Rules» in the applicable operating instructions.

General information
IMPORTANT

• The instructions contained in this manual should be carefully read and observed by all persons who are concerned with the operation, maintenance and inspection of this machine/ front attachment in order to prevent accidents. Especially the «Safety Rules» in the operator’s manual should be read with the utmost care and adhered to.
• In addition, please also observe the accident prevention regulations that apply for your own country. Before commencing with the job, ensure that all the tools and service aids are available.
• Compare existing machine type/front attachment type with the list in the chapter «Shipping Package » and the parts kit supplied. The specification of the components, e.g. bolts, is shown on the shipping package. The shipping package shows the position number (pos. no.)
• of the components. Parts such as nuts and contact washers do not have a position number but belong to the bolt listed above which does have a position number.
• Additional part specifications are the part no., description, measurements, DIN and the quantity. In order to help with the assembly, existing components in the instructions are identified with letters, whereas new parts have been identified with a number (position number). Texts and pictures apply, in general, to all machine types covered by this book and the
• information given applies equally, except where reference is made to a particular model in captions to the pictures or in the main text. Technical data, dimensions and weights are given as an indication only. CLAAS reserve the right to make changes subsequently as technical developments continue. Responsibility for errors or omissions not accepted. IMPORTANT: Front, rear, right and left refer to the direction of forward travel.

TABLE OF CONTENTS:

CLAAS LEXION 480 – 410 Yield meter Fitting Instructions Manual_DE_EN_FR – PDF DOWNLOAD

1 Introduction
Introduction 11
2 Contents
Contents 21
3 General information
Important 31
Identification of warnings and danger signs 32
Correct use of combine 32
4 Shipping Package
Shipping Package 41
Supplementary kit 014 6101 when the 3-D equipment is
available and additionally 683 0251without 3-D 41
5 Installation
Installing the yield meter 51
Preparing the installation 51
Installing the LEM yield sensor with accessories 51
Attaching the fitted hydraulic chain tensioner 53
Removing brace (L) of the chain tensioner 53
Pre-assembling the new chain tensioner device 53
Mounting the chain tensioner device 53
Installing assembled moisture sensor (1) 54
Laying low-pressure lines for machines without 3-D 55
Creating a vacuum in the hydraulic oil tank 55
Removing the fuel tank on machines LEXION 480-440
for hose routing 55
Hydraulic connections for machines with 3-D 58
Hydraulic connections for machines with 3-D 59
Hydraulic connections for machines with/without 3-D 59
Pre-assembling and installing the inclinometer 510
Routing the LEM cable loom with accessories and
installing the LEM module 510
Preparing and performing a test run
