DESCRIPTION:

CLAAS LEXION 480 /460 MTS CLAAS-Terra-Trac Fitting and Operating Instruction manual_GB_EN_FR

INTRODUCTION

The present manual describes how to fit the CLAAS Terra-Trac to the combine harvesters CLAAS LEXION 480 / 460 MTS. This manual only applies when used in combination with the “Combine Harvester Manual”.

TABLE OF CONTENTS:

CLAAS LEXION 480 /460 MTS CLAAS-Terra-Trac Fitting and Operating Instruction manual_GB_EN_FR

Identification plate — basic machine 5
Track roller unit — identification plate 5
Safety decals with pictorials 7
Specifications 13
Fitting Instructions 17
Fitting the rubber track roller unit 19
Test of brake function 29
Aligning the rubber belt on the undercarriage 31
Operation 39
Maintenance 43
Aligning the rubber belt on the undercarriage 45
Tensioning the track roller unit 53
Maintenance 57
Gearbox of drive wheels
and hubs of idler wheels 59
Hubs of front idler wheels 61
Hubs of midrollers 61
Gearbox of drive wheels 61
Gearbox 63
Torque settings of the wheel bolts
of the idlers and half tracks 65
Torque settings for the track drive fixing bolts 65
Torque settings for the axle fixing bolts 65
Lubrication Chart 67
