CLAAS LEXION 560 – 510 Auger Fingers Fitting Instructions Manual DE_EN_FR

Description

CLAAS LEXION 560 – 510 Auger Fingers Fitting Instructions Manual DE_EN_FR – PDF DOWNLOAD

DESCRIPTION:

CLAAS LEXION 560 – 510 Auger Fingers Fitting Instructions Manual DE_EN_FR – PDF DOWNLOAD

INTRODUCTION :

• These instructions describe the safe and timesaving work sequence for retrofitting the finger roller. Retrofitting of the LEXION 560 – 540 combine harvesters, with the supplementary kit part no. 91007594, is possible from the machine number range 58400011.
• Retrofitting of the LEXION 530 – 510 combine harvesters, with the supplementary kit part no. 91007619, is possible from the machine number range 58300011.

• The instructions contained in this manual should be carefully read and observed by all persons who are concerned with the operation, maintenance and inspection of this machine/ front attachment in order to prevent accidents. Especially the »Safety Rules« in the operator’s manual should be read with the utmost care and adhered to.
• In addition, please also observe the accident prevention regulations that apply for your own country. Before commencing with the job, ensure that all the tools and service aids are available. Compare existing machine type/front attachment type with the list in the chapter »Shipping Package« and the parts kit supplied.

TABLE OF CONTENTS:

CLAAS LEXION 560 – 510 Auger Fingers Fitting Instructions Manual DE_EN_FR – PDF DOWNLOAD

1 Introduction
Introduction 1 1
2 Contents
Contents 2 1
3 General
information
Important 3 1
Identification of warnings and danger signs 3 2
Correct use 3 2
4 Shipping Package
Shipping Package 4 1
Supplementary kit parts no 91007594 for
LEXION 560 – 540 and parts no 91007619 for
LEXION 530 – 510 4 1
5 Installation
Installing the finger roller 5 1
Preparing the installation 5 1
Opening the chaff spreader 5 1
Opening the chaff spreader completely 5 2
Removing the chaff spreader transition pan 5 3
Removing the top sieves 5 3
Removing the straw walker return pan 5 5
Removing the straw walker racks 5 6
Fitting the special tool (custom-made) 5 9
Installing the cover plate 5 11
Installing the finger roller 5 12
Fitting the bearing plate to the left 5 14
Fitting the drive flange to the right 5 15
Fitting the bearing plate to the right 5 16
Aligning the finger roller 5 16
Fitting the finger roller drive 5 19
Installing the v-belt pulley of the finger roller drive 5 19
Fitting the upper jockey pulley of the finger roller drive 5 20
Fitting the front jockey pulley of the finger roller drive 5 20
Fitting the rear v-belt pulley 5 21
Fitting the tensioning unit 5 21
Removing the straw walker drive belt 5 21
Putting on and adjusting the finger roller drive belt 5 23
Fitting the rotation speed pick-up 5 24
Installing the straw walker racks 5 25
Installing the straw walker return pan 5 26
Installing the top sieves 5 27
Installing the chaff spreader transition pan 5 28
Folding in the chaff spreader 5 28
Putting on and tensioning the straw walker drive belt 5 29
Adjusting the multiple finger 5 30
