DESCRIPTION:

CLAAS LEXION 580 / 570 LEXION 560 / 550 LEXION 540 / 530 / 520 / 510 Autopilot Fitting Instruction Manual_DE_EN_FR

INTRODUCTION

These instructions describe the safe and time saving procedure for retrofitting the autopilot to LEXION 580 – 510 combine harvesters. The standard mounting time is approx. 4.0 man hours. See page 4.1 for the shipping package. The Safety Rules contained in the applicable Operator’s Manual must be observed.

General
Information
IMPORTANT INFORMATION

• The instructions contained in this manual should be read carefully and observed by all persons who are concerned with the operation, maintenance and inspection of this machine in order to prevent accidents.The “Safety Rules” in the operator’s manual should be read with the utmost care and adhered to.
• In addition, please also observe the accident prevention regulations that apply for your own country. Before starting work, make sure that you have all necessary tools and materials. Compare existing machine type/front attachment type with the list in the chapter “Shipping Package” and the parts kit supplied.
• The specification of the components, e.g. bolts, is shown on the shipping package. Every part listed here has a Part Number. Parts such as nuts and contact washers do not have part numbers. These parts are listed under the part number for the screws with which they are fitted.
• Additional part specifications are the parts no., description, measurements, DIN and the quantity. To make the installation instructions clearer, existing parts are labelled with letters while new parts are labelled with numbers (part numbers).
• In general, texts and pictures apply to all machine models covered by this manual. Notes and comments will alert you to any differences between individual types. Technical data, dimensions and weights are given as an indication only.
• CLAAS reserve the right to make changes at a later date as technical developments continue. Responsibility for errors or omissions not accepted. The indicator boards “front, rear, right and left” are always in direction of travel (forwards)

TABLE OF CONTENTS:

CLAAS LEXION 580 / 570 LEXION 560 / 550 LEXION 540 / 530 / 520 / 510 Autopilot Fitting Instruction Manual_DE_EN_FR

1 Introduction
Introduction 11
2 Contents
Contents 21
3 General Information
Important information 31
Identification of warning and danger signs 32
Correct use 32
4 Shipping Package
Shipping Package 41
Supplementary Kit 41
5 Installation
Installing the Autopilot 51
Preparing the installation 51
Installing the Autopilot valve (1) 51
Installing the steering cylinder (12) with the
wiring loom (13) 54
Routing and connecting the Autopilot wiring loom (17) 55
Installing and connecting the module (21) in
the central terminal compartment 58
Fitting the nominal value sender (23) and the
rocker switch (24) 59
Installing the overrider switch (28) 510
Preparing and performing the test run 511
