Claas LINER 1550 TWIN Profil Operator’s manual – PDF DOWNLOAD

Description

Claas LINER 1550 TWIN Profil Operator’s manual – PDF DOWNLOAD

DESCRIPTION:

Claas LINER 1550 TWIN Profil Operator’s manual – PDF DOWNLOAD

INTRODUCTION

This manual provides information on the use, setting and servicing of the CLAAS rotary swather. The advice on the care and servicing should be followed in order to obtain maximum performance and long service. The assembly and the regular inspection of your machine should be performed by your specialist workshop. Neglect in maintenance and service and incorrect use will result in poor machine efficiency and loss of valuable time. By correct operation and servicing you can make full use of the technical knowledge and experience with which your machine has been designed.
TABLE OF CONTENTS:

Claas LINER 1550 TWIN Profil Operator’s manual – PDF DOWNLOAD

1 Machine description
2 Introduction
Introduction 21
3 Table of contents
4 Preface
Of special importance 41
Identification plate 42
5 Safety instructions
Designated use 51
General safety and accident prevention regulations 51
Identification of warning and danger signs 53
Safety decals with pictorials 54
6 Specifications
LINER 1550 TWIN Profil 61
7 Assembly
Unloading/loading the machine 71
First machine hitch-up 72
8 Prior to operation
Items to check and observe before operation 81
Hitching 82
Attaching to the lower links 82
Universal drive shaft 83
Stand 88
Electrical connections 88
Hydraulic connections 89
Pull rope 810
Mounting the tine arms 810
Parking the machine 811
Parking the machine at subzero temperatures 812
Before transport 813
Road travel 815
9 Operation
Field operation 91
Working position 91
Automatic sequence control 91
Spring tines – Protective strips 93
Rotor height adjustment 94
Setting swath disc 95
Adjusting the swath plate 95
Putting the rotary swather into operation 96
Possible applications 97
Single swath deposition 97
Double swath deposition 910
Steering linkage of the main wheels 912
Transport position 913
Accessory equipment 914
Slip yoke kit 914
Hydraulic couplings for tractors 914
Second windowing rubber 914
Adapter for USA road lighting 914
10 Maintenance
Important maintenance instructions 101
Wheels and tyres 101
Hydraulic system 101
Screws and bolts 101
Lubrication 102
Guards (Safety Frame) 102
Cam drive housing 103
Checking the level of fluid grease; 103
Sealing the swath gearbox 104
Angle drive 106
Drive shafts 107
General information concerning drive shafts 107
Centrifugal running gear 108
Spring adjustment 109
Rotor relief 109
Hydraulics 109
Hydraulic hoses 109
Threaded fasteners 1010
Tine rotors 1010
Frame 1010
Headstock 1010
Spring tine 1011
Fasteners 1011
Safety guards 1011
Tyres 1012
Wheel change 1012
Winter storage 1013
11 Lubrication Chart
Safety precaution 111
Lubricating grease 111
Lubrication 111
