Claas LINER 470 T LINER 350 T Operator’s Manual – PDF DOWNLOAD

Description

Claas LINER 470 T LINER 350 T Operator’s Manual – PDF DOWNLOAD

DESCRIPTION:

Claas LINER 470 T LINER 350 T Operator’s Manual – PDF DOWNLOAD

1 To this operator’s manual
1.1 Notes on the manual
1.1.1 General instructions

• This Operator’s Manual is the original Operator’s Manual. It will be referred to merely as the Operator’s Manual below. This Operator’s Manual is part of the machine. It must be stored at a suitable place and be accessible for driving and operating
• personnel at any time. All users of this machine must have read and understood this Operator’s Manual before operating the machine. Please bear in mind that the CLAAS harvesting machine will also be referred to as machine in the chapters
• below. Have the front attachment maintenance and regular inspections carried out by a qualified specialist workshop as well, e.g. a CLAAS Service Partner. Failure to perform maintenance or incorrect operation lead to a reduction in performance and a loss of time

TABLE OF CONTENTS:

Claas LINER 470 T LINER 350 T Operator’s Manual – PDF DOWNLOAD

TABLE OF CONTENTS
1 To this operator’s manual
11 Notes on the manual 5
2 Safety
21 Safety Tips 7
22 Safety decals on the machine 12
3 Machine description
31 Overview and method of operation 16
32 Options 18
33 Identification plates and identification number 21
4 Operating and control elements
41 Drawbar 23
42 Hydraulic hose line 24
43 Rotor 25
5 Technical specifications
51 LINER 470 T 26
52 LINER 350 T 29
6 Machine preparation
61 Assembling the machine 32
62 Adapting the machine 47
63 Hitching the machine 51
64 Unhitching the machine 55
65 Preparing road travel – LINER 470 T 58
66 Preparing road travel – LINER 350 T 61
7 Operation
71 General safety precautions 62
72 Driving on the road 63
73 Fieldwork settings 65
74 Fieldwork 68
8 Maintenance
81 Maintenance Information 70
82 Operating utilities 74
83 Overview maintenance intervalls 75
84 Maintenance operations in general 78
85 Maintenance operations gearbox 80
86 Maintenance operations drive shaft 82
87 Maintenance operations clutch 83
88 Maintanance operations chassis 84
89 Maintenance operations hydraulic 88
810 Drawbar maintenance work 89
811 Lubrication chart 90
9 Placing out of operation and disposal
91 General Information 94
10 EC-declaraction of conformity
101 LINER 470 T / LINER 350 T 96
4 00 0299 166 5 – LINER 470 T / 350 T – 11/2010
185-002
11 Technical terms and shortcuts
111 Terms and explanations 97
