Introduction

This manual provides information about the installation of the CLAAS Autopilot on 4- 8 row maize headers for the following machine types: Combine DOMINATOR Combine LEXION The shipping package of the components is shown in Fig. 1 and 2. The figures are also intended as an installation aid. The numbering follows the installation sequence. Refer to a separate manual describing the installation of the CLAAS Autopilot to the combine.
TABLE OF CONTENTS:

CLAAS Maize picker head 4- 8 rows CLAAS Autopilot Fitting instructions Manual_DE_EN_FR – PDF DOWNLOAD

COMBINE – DOMINATOR
1 Bracket 2
2 Sensor UH 1
Sensor R/H 1
3 Hex bolts M 8 x 20 2
Hex nut M 8 2
Contact washer A 8 2
4 Support 2
5 Countersunk screw M 8 x 16 DIN 7991-88 2
Hex nut M 8 2
Contact washer A 8 2
6 Hex bolt M 8 x 20 DIN 933-88 2
Self-locking nut VM 8 2
Contact washer S 8 2
7 Wiring loom 1
8 Pipe clamp 12 – 20 26
9 Carriage bolt M 8 x 16 6
Hex nut M 6 6
Contact washer A 6 6
10 Support 2
11 Wiring loom 1
12 Sealant 1
13 Cheese head bolt M 5 x 30 DIN 84 6
Lock washer 5 6
Hex nut M 5 6
14 Support 1
15 Cable strap 6
16 Pipe clamp 4
17 Hex bolt M 8 x 25 DIN 933-88 4
Hex nut M 6 4
Contact washer 4
18 Pipe clamp 16/20 1
