DESCRIPTION:

CLAAS MEDION 340/330/310 Electric deflector adjustment system Fitting Instructions Manual_DE_EN_FR

INTRODUCTION

These instructions describe the safe and timesaving work sequence for retrofitting an electric deflector adjustment system. Retrofitting of the MEDION 340/330/310 combine harvester, with the supplementary kit part no. 299 235.0, is possible from the following machine number ranges: 9320011 and 9340011. The standard mounting time is approx. 2 man hours. See page 4.1 for the shipping package. Observe the »Safety Rules« in the applicable operator’s manual.
TABLE OF CONTENTS:

CLAAS MEDION 340/330/310 Electric deflector adjustment system Fitting Instructions Manual_DE_EN_FR

1 Introduction
Introduction 11
2 Contents
Contents 21
3 General
information
Important 31
Identification of warnings and danger signs 32
Correct use 32
4 Shipping Package
Shipping Package 41
Supplementary kit parts no 011 2130 41
5 Installation
Installing the electric deflector adjustment system 51
Preparing the installation 51
Attaching the mechanical components 51
Installing the plug-in-type module (9) 52
Laying the wiring loom (14) to the linear motor (5) 53
Laying the wiring loom (14) to the switch console 56
Attaching and connecting the turn switch (22) 56
Performing a test run! 58
