CLAAS MEDION 340 / 330 / 320 / 310 Chaff Spreader Fitting Instructions Manual_DE_EN_FR

Description

CLAAS MEDION 340 / 330 / 320 / 310 Chaff Spreader Fitting Instructions Manual_DE_EN_FR

DESCRIPTION:

CLAAS MEDION 340 / 330 / 320 / 310 Chaff Spreader Fitting Instructions Manual_DE_EN_FR

INTRODUCTION

These instructions describe the safe and timesaving work sequence for retrofitting the chaff spreader for the combine harvester MEDION. Range of machine numbers: Supplementary kit parts no. 000 538 812 0 from 93400011 Supplementary kit parts no. 000 538 820 0 from 93200011 See page 4.1 for the shipping package. Observe the »Safety Rules« in the applicable operator’s manual

General
information
IMPORTANT

• The instructions contained in this manual should be carefully read and observed by all persons who are concerned with the operation, maintenance and inspection of this machine/ front attachment in order to prevent accidents.
• Especially the »Safety Rules« in the operator’s manual should be read with the utmost care and adhered to. In addition, please also observe the accident prevention regulations that apply for your own country. Before commencing with the job, ensure that all the tools and service aids are available.
• Compare existing machine type/front attachment type with the list in the chapter »Shipping Package« and the parts kit supplied. The specification of the components, e.g. bolts, is shown on the shipping package. The shipping package shows the position number (pos. no.) of the components.
• Parts such as nuts and contact washers do not have a position number but belong to the bolt listed above which does have a position number. Additional part specifications are the part no., description, measurements, DIN and the quantity. In order to help with the assembly, existing components in the instructions are identified with letters, whereas new parts have been identified with a number (position number).
• Texts and pictures apply, in general, to all machine types covered by this book and the information given applies equally, except where reference is made to a particular model in captions to the pictures or in the main text. Technical data, dimensions and weights are given as an indication only.
• CLAAS reserve the right to make changes subsequently as technical developments continue. Responsibility for errors or omissions not accepted. Front, rear, right and left refer to the direction of forward travel

TABLE OF CONTENTS:

CLAAS MEDION 340 / 330 / 320 / 310 Chaff Spreader Fitting Instructions Manual_DE_EN_FR

1 Introduction
Introduction 11
2 Contents
Contents 21
3 General
information
Important 31
Identification of warnings and danger signs 32
Correct use 32
4 Shipping Package
Shipping Package 41
Supplementary kit MEDION 340 and
for MEDION 330/320/310 41
5 Installation
Installing the chaff spreader 51
Preparing the installation 51
Installing the spreader with accessories 51
Removing v-belt pulley of the straw walker drive 53
Installing the drive with accessories 55
Tensioning v-belt of the straw walker drive 57
Tensioning v-belt of the intensive separation system drive 57
Installing the safety frame with accessories 58
Attaching stickers 59
Preparing and performing the test run 510
