Claas PU 300 HD Type 905 JAGUAR 900 / 890 / 870 / 850 / 830 Type 493 Operator’s Manual – PDF DOWNLOAD

Description

Claas PU 300 HD Type 905 JAGUAR 900 / 890 / 870 / 850 / 830 Type 493 Operator’s Manual – PDF DOWNLOAD

DESCRIPTION:

Claas PU 300 HD Type 905 JAGUAR 900 / 890 / 870 / 850 / 830 Type 493 Operator’s Manual – PDF DOWNLOAD

INTRODUCTION

• This fitting and operating instruction manual provides information on the use, adjustment and operation of the CLAAS Pickup.
• The advice on care and servicing should be followed in order to obtain maximum performance and long service from the machine. The assembly and regular inspections of your machine should be carried out by your specialist workshop.
• Neglect in maintenance or service or incorrect use will result in poor machine efficiency and loss of time.
• Make use of the experience and latest developments incorporated in this machine by correct operation and careful maintenance and the machine will always give you good service.

4 Preface
OF SPECIAL IMPORTANCE

• Please also note that the CLAAS Pickup is also called the machine in the following chapters. The notes in this fitting and operating manual should be read and observed by all persons who are involved in the use, maintenance, repair or monitoring of the machine.
• In order to provide a better illustration, some of the guards and covers have been removed for this purpose. all guards and covers must be replaced before the machine is started! Pay particular care when reading the sections “Safety rules« and »Prior to operation«.
• The use of spare parts, accessories, and ancillary equipment not originally manufactured by CLAAS, or which have not been checked and approved by CLAAS, can change the specified design characteristics of the CLAAS machine or can detract from its functional performance, with a possible adverse effect on the active and/or passive safety of the machine and its working safety (accident prevention).
• CLAAS are in no way liable for any damage or personal injury caused through the use of parts, accessories, and ancillary equipment other than original CLAAS parts. Technical specifications, dimensions, and weights cover the corresponding tolerances. CLAAS reserves the right to make subsequent changes in the course of technical developments. Front, rear, right, and left always refer to the direction of travel.

TABLE OF CONTENTS:

Claas PU 300 HD Type 905 JAGUAR 900 / 890 / 870 / 850 / 830 Type 493 Operator’s Manual – PDF DOWNLOAD

1 Machine overview
2 Introduction
Introduction 21
3 Table of contents
4 Preface
Of special importance 41
Identification plate 42
5 Safety rules
Correct use 51
General safety and accident prevention regulations 51
Identification of warning and danger sings 52
Safety decals with pictorials 53
6 Specifications
PU 300 HD 61
7 Assembly
Unloading / loading the machine 71
Unpacking the machine 72
Machine assembly 73
Release the lock mechanism 74
Hitching the Pickup 74
Supporting the Pickup 75
Closing the lock mechanism 75
Adjusting the lock mechanism 76
Connecting the hydraulics 76
Fitting the land wheels 77
Fitting the universal drive shaft 77
8 Prior to operation
First hitch the Pickup 81
Connecting the universal drive shaft 82
Setting the dog clutch 83
Working position 84
Working position land wheels 84
Working position prop stand 85
Setting the working height 86
Setting the Pickup lowering speed 86
Check and observe the following points prior to operation 87
Fitting the Pickup 88
Before transport 89
Transport position 89
Road travel 810
Removing and disengaging the Pickup 811
Extending the prop stands 811
Removing the universal drive shaft 812
9 Operation
Field operation 91
Lifting/lowering the Pickup 91
Lifting/lowering the roll type crop guard or intake augers
hydraulically 91
Using the Pickup 92
Setting the Contour-System (ground pressure regulation) 93
Single paddle – extension 94
Adjusting the pick-up unit 95
Distance between intake auger and bottom of trough 96
Speed change of the intake auger 97
Roll type crop guard with hydraulic lift out 99
Accessory equipment 910
Hydraulic auger lifting 910
Cover rails for the intake shafts 910
Fitting kit gauge wheel 910
Hydraulically folding land wheels 911
10 Maintenance
Important maintenance instructions 101
Hydraulic system 101
Screws and bolts 101
Lubrication 101
Safety guards 101
Wheels and tyres 102
Drives 103
Angle drive 103
Tensioning the drive chains 104
Drive chain pick-up 104
Drive chain intake auger 105
Couplings 106
Universal drive shafts 107
Hydraulics 108
Hydraulic hoses 108
Fasteners 108
Threaded fasteners 108
Safety guards 109
Tyres 109
Tyre pressure 109
Winter storage 1010
11 Lubrication chart
Safety rules 111
Lubricants 111
Lubrication 111
