DESCRIPTION:

CLAAS ROLLANT 255 UNIWRAP Fitting Instruction Manual _DE_EN_FR – PDF D OWNLOAD

Introduction

This manual describes the procedure to be followedfor equipping the Rollant 255 Uniwrap balers with wrapper the tipping body bearings. Carefully follow the «Safety Rules» described in the operators manual

Safety regulations

Important

• To prevent accidents, these instructions must be read by everyone who uses the machine/ attachment and who deals with maintenance, servicing or inspection. It is advisable to pay particular attention to the section headed
• Safety precautions in your operator’s manual as well as to comply with the regulations for the prevention of accidents that are in force in your country Before starting work, make sure that all the necessary tools and attachments are ready for use. Compare the type of machine/attachment on hand, the list which appears in the section headed
• “Scope of parts” and the ready-to-assemble parts supplied. Specification of the parts, for example the screws, appears in the list headed “Scope of parts”. In this list each assembly component is identified by an item number (item no.) Parts such as nuts and contact washers are not identified by an item number.
• These components form part of the item number of the screw with which they must be assembled. Other instructions stated on these components are the spare part number, the description, the dimensions, DIN and the quantity supplied. In the assembly instructions, the available parts are identified by letters and new parts by numbers (item numbers) to act as a better guide.
• Texts and pictures have been kept neutral whenever possible. Text references point out the differences between the individual types. Technical data, dimensions and weights are given as an indication only.We reserve the right to errors and technical changes as part of ongoing technological developments.
• The terms front, rear, right and left always refer to the machine as seen in the direction of forward travel.

TABLE OF CONTENTS:

CLAAS ROLLANT 255 UNIWRAP Fitting Instruction Manual _DE_EN_FR – PDF D OWNLOAD

Anbauanleitung 3
Kippmuldelagerung 3
Einführung 5
Wichtig 7
Kennzeichnung von Warn- und Gefahrenhinweisen 8
Allgemeine Sicherheits- und Unfallverhütungsvorschriften 8
Abstellen der Maschine 8
Bestimmungsgemäße Verwendung 8
Lieferumfang (0852 0520) 9
Vormontage13
Montage linke Seite13
Montage rechte Seite15
Assembly instructions17
Tipping body bearings17
Introduction19
Important21
Marking of warning and danger notes22
General safety regulations and instructions for the avoidance of accidents22
Leaving the machine22
Intended use22
Scope of parts(0852 0520)23
Preassembly27
Assembly on left side27
Assembly on right side29
Notice de montage31
Paliers basculeur31
Introduction33
Important35
Caractérisation des indications sur les dangers36
Consignes générales de sécurité et de prévention des accidents36
Stationnement de la machine36
Utilisation conforme à la destination36
Lot de pièces (0852 0520)37
Prémontage41
Montage côté gauche41
Montage côté droit43
